Air Cooled Modular Chiller1)Classical design Easy application
2)R22 CE MOQ 1 set
3)Customers first
Air Cooled Modular Chiller
Feature
-Energy-efficient: The ratio output against input is coefficient of performance (COP). Normally it can be more than 4.
-Environmental protection : There is no waste water, waste residue, used heat, the waste gas discharged. It will not produce any pollution to the atmosphere and environment.
-Modular controlling function: As per the actual requirements, one or more units can be added to combine a heat water supply system, which are controlled by modular.
-Automatic energy balance: According to ambiguous controlling principle, the unit checks the load dynamically.when the unit reaches the setting temperature, the unit keeps the load in balance.
Parameter
| Model | H-Ach45T/3 | H-Ach55T/3 | H-Ach65T/3 | H-Ach88T/3 | H-Ach108T/3 | ||
| Cooling Capacity | kW | 45 | 55 | 65 | 84 | 103 | |
| Heating Capacity | kW | 47 | 57 | 68 | 88 | 108 | |
| Rated Input Power | Cooling | kW | 13.74 | 16.67 | 22.25 | 25.81 | 34.25 |
| Heating | kW | 13.54 | 16.56 | 21.71 | 26.56 | 34.73 | |
| Rated Input Current | Cooling | A | 23 | 27 | 36 | 44 | 56 |
| Heating | A | 23 | 28 | 37 | 44 | 58 | |
| Power Supply | 3N 380V 50Hz | ||||||
| Compressor | Type | Scroll Type | |||||
| Quantity | 4 | 4 | 4 | 2 | 2 | ||
| Fan Quantity | Sets | 2 | 2 | 2 | 2 | 2 | |
| Refrigerant Charge | kg | 14 | 16 | 18 | 24 | 32 | |
| Refrigerant | R22(please inform us for R410A) | ||||||
| Ambient Temperature | -7°C~43°C | ||||||
| Control Manner | Central control and network control | ||||||
| Protection | High/low pressure protection, freezing-proof protection, over-current protection, water-break protection | ||||||
| Noise | dB(A) | 60 | 61 | 63 | 65 | 66 | |
| In/Out Water Gap Spec | DN50 | DN65 | DN65 | DN125 | DN125 | ||
| Net Dimension(LxWxH) | mm | 1800×890×1615 | 2000×1000×1800 | 2000×1000×1800 | 2160×1280×2100 | 2160×1460×2110 | |
| Net Weight | kg | 560 | 650 | 780 | 1020 | 1290 | |
| ross Weight | kg | 595 | 690 | 825 | 1080 | 1380 | |
|
Note: 1) Nominal cooling conditions: condenser air inlet dry bulb temperature: 35°C, wet bulb temperature: 24°C, evaporator water inlet temperature: 12°C, water outlet temperature: 7°C 2) Nominal heatling conditions: outdoor dry bulb temperature: 7°C, wet bulb temperature: 6°C, evaporator water inlet temperature: 40°C, water outlet temperature: 45°C | |||||||
Product show
