Standalone Fingerprint Reader
Fingerprint access control with OLED display
Product Introduction of Standalone Fingerprint Reader
F30 fingerprint access control multifunction machine is a new developed fingerprint product based on ARM9 platform. The perfect Wiegand signal and door access machine function, which can be used alone as a access controller also can be connected to any other controllers on the market. With the Wiegand in function, reader can be connected from external to the machine . Suitable for banks, armies, offices etc..
Product Features:
1) Using the low power self-luminous OLED display ,with a wide viewing angle;
2) The standard USB communication, RS485 read, U disk to download, TCP/IP network, meet the requirement of the data transfer in different environments;
3) With the built-in RF ID card reader module, the optional Mifare module;
4) Wiegand input and output, wired doorbell, relay output, magnetic interface, alarm signal output interface, so that the product has high expansibility in application.
5) Fingerprint, card, password and so on, many kinds of recognition methods, ensure the integrity and security of data;
6) Device support Multi-language adjustable, English,Japanese,Korean,Thai,Indonesian,
Tieng Viet,Spanish,French,Portuguese,German,Turkish,Italian, Czech,Farsi,Arabic
Technical parameters of Standalone Fingerprint Reader
hardware platform |
ARM9 |
fingerprint collector |
Fingerprint sensing optical Blue ray fingerprint collector |
Screen |
128 X 64 self-luminous OLED screen |
Fingerprint Capacity |
1000(standard),Can be extended to 3000,5000 |
Record Capacity |
100000 |
Communication Modes |
USB, RS485, TCP/IP |
U disk Function |
Support upload and download |
ReadCard module |
The standard 125K HZ RFID and optional 13.56MHZ Mifare |
Name Display |
Display |
Wiegand |
In&out |
Recognition Speed |
<1second |
FRR |
<1% |
FAR |
<0.0001% |
Temperature of use |
-25°C~45°C |
Work humidity |
20%~80% |
Power supply |
+12V |
Size |
115mm X 105mm X 29.5mm |
After checking the details picture of the FP reader,do you want to try?
Pls do not hesitate to contact me at: skype ID: crypton0901
....
