outdoor fingerprint lock
Product Introduction:Fingerprint Standalone waterproof access control
Product Features:
1) Waterproof structure design,IP65 waterproof
2) Internal electric lock control directly,the out switch,magnetic detection(independent control mode)
3) Capacitance induction type fingerprint collector, standby and power nap function.
4) The standard 125KHz RFID card module and optional Mifare module, realize the combination of card and fingerprint;
5) The standard remote keying function and the administrator function, we can effectively operate the equipment without needing connection to any of the PC machines. Operation is more convenient.
6) Wiegand signal output, can combine with all standard controller
7) RS485 communication function
Product Parameter:
Hardware platform |
ARM9 |
Fingerprint collector |
Fingerprint sensing optical Blu ray fingerprint collector |
Fingerprint Capacity |
500(standard),Can be extended to 1000,3000 |
Administrator Function |
support 2 groups of administrators to register and delete |
ReadCard module |
The standard 125K HZ RFID and optional 13.56MHZ Mifare |
Wiegand |
WG26 output |
Recognition Speed |
<1second |
LED |
Red&Blue |
Alert Tone |
Buzzer |
Alarm Function |
Anti-dismantle,Force to open door, Open door overtime |
Temperature of use |
-25°C~50°C |
Work humidity |
20%~80% |
Power supply |
+12V |
Size |
134mm*55mm* 24mm |
More options to you :
