Automatic Welded Wire Mesh Machine Welding Mesh Making Machine
- xingang
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | Youjie | |
| Model Number | YJ-LLY-025 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
automatic welded wire mesh machine welding mesh making machine
machine name:
welded wire mesh machine/welded mesh machine/wire mesh welding machine
Construction welding mesh machine/Steel bar mesh welding machine
Reinforcing mesh welding machine
parameters of machine
| wire diameter | 5.0-12mm | line wire | pre-cut wire |
| weft distance | minimum 25 mm | weft wire | pre-cut wire |
| line distance | 100-300mm | rated voltage | 380v |
| width | 2500mm | rated power | 140KVAx12 |
| welding speed | 25 times/min | dimension | 2400x6000x2650mm |
| welding No. | 24 | mesh length | 6000mm |
Advantage of Machine:
1.It adopts synchronous control skill. The welding time and separate welding are controlled by
computer based on windows operation system, which makes the operation more intelligent.
2.The longitudinal wires are fed continually in coils, which can be straightened, cut, welded,
and placed in order automatically.
3.Mesh drawing system is controlled be servo motor which improves the precision of mesh opening
size, meanwhile the longitudinal and transversal spacing are adjustable.
4.The major feature of this machine is that is realizes continual welding in coil wires.
5.It simplifies the process that every tensile spring has to be changed when the welding wire
diameter is different.
mesh application:
High way, railway, bridge, enclosure mesh, fencing construction and so on.
finished product:
