2013 Newest HW Series Soft-loop Forming Machine

2013 Newest HW Series Soft-loop Forming Machine thumbnail-1
2013 Newest HW Series Soft-loop Forming Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Bag Forming Machine
Bag Type:
Soft Loop Handle Bag
Contact Supplier Request Quote Chat Now
Ruian Huana Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Bag Forming Machine
Bag Type Soft Loop Handle Bag
Material Plastic
Computerized Yes
Place of Origin Zhejiang, China
Brand Name Huana
Model Number HW
Power(W) 1KW
Dimension(L*W*H) 1700*1700*1500
Certification BV
Warranty 1YEAR
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. production speed 30pcs/min
ft-loop handle bags
petitive price

2013 Newest HW Series Soft-loop Forming Machine





Soft-hand ring bag machine is behind the release of a vice-Rack, vice expected to equal the width of the hand-held length of the





Product Name: Fully Automatic Soft Handle Bag Making Machine
Description:

1. The machine is applicable to high/low polyethylene plastic film.

2. Electrical control adopts CRT real-time display system, the needed parameter can be set up according to different products.

3. All the temperature control systems adopt electronic liquid crystal digital displayer.

4. Bothportable rings can seal at one time, and the seal is excel lent.

5. The machine possesses the automatic alarm functions of color mark losing. Temperature exceeding limit, counting down and the deliver of finished products.

6. Bag delivery adopts stepping motor special control system, the main machine
Is controlled by soft start-up transducer, tranquilization in course.

7. All the four-layer film of the machine has been warm-up before side-sealing, which make the seal quite fast.

8. All the pneumatic Component and electrons adopt famous mark at home or

abroad.







 2013 Newest HW Series Soft-loop Forming Machine



1. Fully automatic
2. For soft-ring hand-held bag

automatic soft-ring hand-held bag machine; soft-ring hand-held bag making machine; bag machinery

Soft-hand ring bag machine is behind the release of a vice-Rack, vice expected to equal the width of the hand-held length of the article, this pair is expected to cut into the long and narrow strip, and deliver it into the top part of the fold, soft bag of hand-held vice Material transportation systems using stepper motor transport, it has a precision of deputy expected to send, seal cutting, and at the same time the accuracy of the Seal in the center of the bag.



250mm-600mm wide bags
Thick bag 0.05-0.2 kg
Power AC220V
Speed 18pcs/min
Machine dimensions (L × W × H) 1.65m × 1.56m × 1.24m
