Help CenterPaper Slitting Machine
Related Products
Specifications
1. material: BOPP, PET, CPP, CRE, PVC, PE, foil-alum, peper,etc.2. Durable in quality
3.Full- Automatic
Paper slitting machine
Use:
This machine is suitable for BOPP,PET,CPP,PVC,paperand film in roll ect.
Features:
1. Equipment production requirements: the device can cut all kinds of nonwoven fabrics,such as
Hot-rolled nonwoven ,Spunlace nonwoven fabric,Plastic film; Kraft paper, etc.
2.Raw material effective width: 2000mm , feeding material Maximum Diameter:1000mm
3.Pneumatic automatic feeding system, maximun holding weight 500kg more or less ,
it's convenient to operate for workers.
4. The device working principle: Automatic feeding ,magnetic powder conveying, automatic cutting ,
automatic cross,magnetic powder control the winding to count down.
5.Adopting air swelling shaft roll furling roller, convenient for production
6. The device has a wide belt synchronous to convey and two sets of gear stepless variable speed to adjust tension ,
to ensure that output cutting size accurately with positive and negative guide conversion set
Main technical Parameter:
Main Technical Variables |
WFQ-1000 | WFQ1300 |
| max dia | 600 | 600 |
| max width | 1000 | 1300 |
| paper inner dia | 76 | 76 |
| cutting dimension | 20-1300 | 20-1300 |
| cutting tension | 160 | 160 |
| accurancy of adjustment | +/-0.5 | +/-0.5 |
| moto power | 3.8 | 4.8 |
| weight | 1500 | 1650 |
| overall dimension | 2200x1300x1500 | 2450X1300X1500 |
Pictures of machine
Delivery&Package:
1) Delivery time -30 days after receiving the deposit
2) Package wooden package
3) Brand Huana
4) Port Ningbo/Shanghai
· 12 months warranty (except for spare parts)
· 24 hours online service
· Providing free quick-wear parts
· Engineers available to service overseas if necessary
· Product certificated by ISO9001
.............................................................................................................................................................................
We deeply know that we cannot succeed without every client
Have any require ,you could contact with us:
Add:Xiachang Street, Feiyun Villiage,Ruian Town, Zhejiang Province, China.
Tel:+86-577-66852022/66852020
Fax:+86-577-66852021
Skype:lynn.lin875
