Multi-function electric parameter tester AC voltage,current ,DC VOLAGE CURRENT Meter
Main Technology Parameters
Operating power |
AC85V~265V |
Power consumption |
<2W |
Working frequency |
45~65Hz |
|
|
Sampling Rate
|
2 t/s |
Display |
digital LED display |
|||
Over range Indication |
"HHHH" |
Dimension |
128.0mmx135.0mmx32.0mm[1] |
Mounting |
mounting screw |
|
Operating Temperature |
0~50℃ |
Working Relative Humidity |
≤85% RH |
|||
AC Specification:
AC power range |
0~2500W |
Power Resolution
|
0.01W[2] |
Power accuracy |
0.5%FS |
AC Voltage range |
AC85V~265V |
Voltage Resolution |
0.1V |
Voltage Accuracy |
0.5%FS |
AC current range |
AC0~10A |
Current Resolution |
0.001A |
Current Accuracy |
0.5%FS |
Power factor range |
0~1.000 |
PF Resolution |
0.001 |
PF Accuracy |
0.5%FS |
Frenquency range |
45.0Hz~65.0Hz |
Frequency Resolution |
0.1Hz |
Frequency Accuracy |
0.5%FS |
DC Specification:
DC power range |
0~1000W |
Power Resolution |
0.01W[2] |
Power accuracy |
0.5%FS |
DC Voltage range |
DC0~100V |
Voltage Resolution |
0.01V |
Voltage Accuracy |
0.5%FS |
DC current range |
DC0~10A |
Current Resolution |
0.001A |
Current Accuracy |
0.5%FS |
Ac/dc measurements ):
Efficiency measurement range |
0~100% |
Efficiency Resolution |
0.1 |
Efficiency Accuracy |
0.5%FS |
