Pure Sine Wave dc to ac Power Inverter 1800w

Pure Sine Wave dc to ac Power Inverter 1800w thumbnail-1
Pure Sine Wave dc to ac Power Inverter 1800w photo-1
Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
XANTREX
Model Number:
Prosine 1800i
Contact Supplier Request Quote Chat Now
EastWest Energy Technology Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Beijing, China
Brand Name XANTREX
Model Number Prosine 1800i
Output Power 1 - 200KW
Size 115 x 280 x 390 mm
Weight 7.5kg
Input Voltage 12V/24V/48V
Output Voltage 220V/230V/240VAC
Type DC/AC Inverters
Output Frequency 50Hz±0.05%
Output Current 20A

Specifications

1.remote switcher feature
2.12V, 24V
3.True sine wave output
4.Two year warranty
5.Schuko AC receptacle

Specification of pure sine wave dc to ac power inverter  1800w:

Product  Information:

1000 Watt and 1800 Watt 230V/50Hz Sine Wave Inverter

Offering superior quality sine wave output, the Prosine 1000i and Prosine 1800i stand-alone

inverters are ideally suited for electrical systems that already have a quality multistage battery

charger. Designed for recreational and industrial applications, Prosine inverters are suitable for

both heavy duty and sensitive electronic loads. The inverters are lighter and more compact than

others with similar power ratings because they use high-frequency switching technology in the

power conversion process.

Ultra-Clean True Sine Wave Power:

With less than 3% total harmonic distortion, the Prosine delivers true sine wave output that is

identical to AC power supplied by your utility. Expect trouble-free true sine wave electricity for

televisions, audio systems, variable speed tools, and more.

Product Features

Two models available: 1000 watt (1500 watt surge) and 1800 watt (2900 watt surge)

True sine wave output

Removable LCD display can be mounted remotely for control and monitoring

Unique DC terminals offer 180-degree connections for easy installation in tight places

Efficient powersave mode draws only 1.5 watts under no load condition

Two year warranty



Protection Features

Over temperature shutdown and automatic overload protection

Over voltage and under voltage protection

Short circuit and AC backfeed protection



Options

Available in 12 and 24 volt models

Schuko AC receptacle

Remote interface kit for remote mounting of display module

Models available with Schuko, hardwire, or hardwire with transfer switch

Electrical Specifications:

Model

Prosine 1000i

Prosine 1800i

Output power

1000 watts

1800 watts

Surge rating

1500 watts

2900 watts

Peak output current

11A

20A

Output voltage (at no load)

230 VAC RMS +/-3%

230 VAC RSM +/-3%

Output voltage (over full load and battery voltage range)

230 VAC RMS +4%, -10%

230 VAC RMS +4%, -10%

Output frequency

50 Hz+/-0.05 (crystal controlled)

50 Hz+/-0.05 (crystal controlled

Output waveform

True sine wave (<3% THD)

True sine wave (<3% THD)

Peak efficiency

90%

90%

No load power draw (search mode)

<1.5 W

<1.5 W

No load power draw (idle mode)

<22 W

<22 W

Input voltage range (12 V/24 V)

10 - 16 VDC / 20 - 32 VDC

10 - 16 VDC / 20 - 32 VDC

Transfer relay rating (hardwire/transfer relay models)

10A

10A

Transfer time AC to inverter and inverter to AC

Max 2 cycles (typically 1 cycle) <2.5 seconds with Powersave “ON”

General Specifications:

Model

Prosine 1000i

Prosine 1800i

Output power

1000 watts

1800 watts

Surge rating

1500 watts

2900 watts

Peak output current

11A

20A

Output voltage (at no load)

230 VAC RMS +/-3%

230 VAC RSM +/-3%

Output voltage (over full load and battery voltage range)

230 VAC RMS +4%, -10%

230 VAC RMS +4%, -10%

Output frequency

50 Hz+/-0.05 (crystal controlled)

50 Hz+/-0.05 (crystal controlled

Output waveform

True sine wave (<3% THD)

True sine wave (<3% THD)

Peak efficiency

90%

90%

No load power draw (search mode)

<1.5 W

<1.5 W

No load power draw (idle mode)

<22 W

<22 W

Input voltage range (12 V/24 V)

10 - 16 VDC / 20 - 32 VDC

10 - 16 VDC / 20 - 32 VDC

Transfer relay rating (hardwire/transfer relay models)

10A

10A

Transfer time AC to inverter and inverter to AC

Max 2 cycles (typically 1 cycle) <2.5 seconds with Powersave “ON”

Regulatory Approvals:

CE Mark - Low Voltage Directive 2006/95/EC (EN 50178:1997)

EMC Directive 2004/108/EC (EN 61000-6-1:2007 & EN 61000-6-3:2007)

Automotive EMC Directive 2004/104/EC as amended by 2005/83/EC

Note: Specifications subject to change without notice.

Certificate:

pure sine wave dc to ac power inverter 1800wpure sine wave dc to ac power inverter 1800w
