Help Center1200W DC to AC Power Inverter
Related Products
Specifications
1. Intelligent cooling fan speed control determined by loads2.Optional bypass
3.Remote switcher feature
4.EMC, IEC standard
Specification of 1200W DC to AC power inverter
Introduction:
ParaWatt series inverter is a leading product in the industry, which has high cost performance. LED indicating lights can work under -25°C ambient temperature. The single version display mode REMOTE01 can display the parameters through LCD also.
Designed with the highest standards in the industry, ParaWatt series inverter realizes remotely controlled, intelligent and high efficiency. The optional data loggers ADM-01, ADM-BLUE, ADM-GPRS can realize monitor and control function through computer, blue-tooth, GPRS respectively, and can monitor and control several inverters at the same time.
Advanced circuit design and high standard choice of components maximized its adaptability to inductive and capacitive loads. ParaWatt series inverter can be used in cars, yachts and solar systems.
The superior performance and reliable quality makes ParaWatt series inverter the best choice for your requirements.
Intelligent and high efficiency :
• Intelligent ‘power saving mode‘, no higher than 7W.
• Intelligent cooling fan speed control determined by loads.
• Pure sine wave output(THD<3%) for wide range of applications and different environment.
Convenient :
• Optional bypass.
• Modular design enables more flexible and room saving way to combine and split.
Safety and reliability :
• Input/output isolated design maximized the operation safety.
• Intelligent multiple protection: Input low voltage / Overload / Short circuit / Low battery alarm / Input over voltage / Over temperature.
Remote control :
• Remote switcher feature.
• Display inverter parameters remotely.
Specification:
XXX |
Rated output power |
1200 |
1200w |
1500 |
1500w |
bc |
Nominal DC voltage |
12 |
12V dc |
24 |
24V dc |
OUtput
Nominal AC voltage |
220/230/240Vac 100/110/120Vac |
AC power frequency |
50/60Hz +-0.1% |
Max. Efficiency |
92%(48V)/ 91%(24V)/ 90%(12V) |
Output THD |
<3% |
Crest factor |
3:1 |
Input
Nominal DC voltage |
12Vdc/24Vdc/48Vdc |
|
Voltage range |
10.5-15.5Vdc(*1,*2,*4) |
|
No load current draw |
≤15W |
|
Stand-by current draw |
≤7W, power saving mode |
|
Interface |
RS485 |
Protection
Input low voltage protection |
10.5V /21V/42V protect, 11V/22V/44V alarm(automatically recovery or not automatically recovery can be factory set) |
Input overload protection |
18V/32V/64V protect, 15V/31V/62V alarm (automatically recovery or not automatically recovery can be factory set) |
Reverse current protection |
Fuse |
Input over voltage |
120% rated voltage |
Output low voltage alarm |
80% rated voltage |
Output over current point1 |
10m 125% |
Output over current point2 |
10s 150% |
Output short circuit protection |
Recovery |
Over temperature protection |
90°Crecovery |
Fan fault protection |
turn off output, alarm |
