RFI TLA4100 - 6dBi Transit/Low Profile Mobile Antenna
RFI TLA4100 - 6dBi Transit/Low Profile Mobile Antenna
RFI TLA4100 - 6dBi Transit/Low Profile Mobile Antenna
- Wideband 700-2700MHz performance
- Low profile, vandal resistant radome
- Ground dependent/independent capable
The TLA4100 Antenna is designed specifically for rail, light rail and bus applications and other similarly demanding transit or stationary applications. With a VSWR less than 2.5:1 covering 698 - 2700 MHz, the TLA4100 operates in all cellular bands globally plus the 2.4 GHz ISM band. This antenna also unofficially operates on 2300MHz @ VSWR approximating 1.35:1.
This antenna can be used in both a ground independent and ground dependent installation - maximum gain is achieved by using up to a 1m^2 metal surface as a ground plane.
Designed to meet the following European Traction Industry Standards:
- NF-F-16-101/102 (materials standard)
- EN50155 (vibration standard)
- EN50124-1 (electrical isolation standard)
- Deutsch Bahn high voltage / current specification
Roof mount multiband "Shark Fin" style antenna designed to operate on all mobile phone and wireless broadband frequencies within the one housing. An alternative for use where height is an issue eg. roofs on large motor homes, outdoor data/weather reporting stations, and many more.
Designed utilising a high impact, UV stabilised low Flame, Smoke and Toxicity (FST) radome, the TLA4100 is IP68 rated to fully protect against the ingress of dust and water. This antenna is suitable for installations even in the most demanding of climates.
Streaming live in-car video at Bathurst with two RFI TLA4100 for 4G mobile broadband.
Electrical Specifications
Frequency Range: 698-960MHz & 1710-2170MHz & 2400-2700MHz & 5700-5800MHz
Input Impedance: 50Ω
VSWR: <2.5:1
Vertical Beamwidth: 38° @ 698-960MHz & 180° @ 1710-2700MHz
Polarisation: Vertical
Radiation: Omnidirectional, Ground Dependent
Maximum Power: 50Watts
Mechanical/Environmental Specifications
Construction: NF-F-16-102 compliant injection moulded radome / cast aluminium alloy base
Cable: None
Connector: N Female
Mount: 4 x M6 screws (not included)
Dimensions: 205 x 100mm (L x W)
1* RFI TLA4100 - 6dBi Transit/Low Profile Mobile Antenna
Shipping terms
1-2 days for sample order, 3-5 days for bulk order
Customer Service
1. OEM&ODM service offered
2. Sample’s fee can be refunded after order reaches 1000 sets
3. Delivery can be express: DHL, UPS,FedEX, EMS,TNT
Warranty
Before delivey, we will check the item’s quality strictly one by one. Life –warranty for radio host &accessores, please contact us immediately when you get defective, thanks.
Payment terms
Payment: Paypal, T/T, Western Union (please do not believe anybody by mail say our bank change, thank you)
Contact us
Mario Lin
Tel:0086-15880011801
WhatAapp: 8615880011801
Q: Are you a factory or a trading company?
A: We are professional manufacturer of two way radio accessories, mainly radio antennas.
Q: Can I buy with my own logo?
A: Yes, custom logo is available, but extra charge will cost.
Q: Can it work with all brands radios?
A: Yes, it can work with all brands of radios, in antenna frequency range. Signal will be strongest when in middle frequency.
Q: What is the leading time if I place the order?
A: Normally 3-5 days for delivery, if urgent order, pls contact us for details.
Q: What type of delivery method do you offer?
A: Small order by express courior, such as DHL, Fedex, TNT, UPS, EMS etc.
Mass order by air, by load or by load.
Q: What type of payment terms do you accept?
A: L/C, T/T, D/P, D/A etc.
