Help Center302 304 304L 306 306LStainless Steel Conveyer Belt Mesh
Related Products
-
Conveyer Belt MeshUS$ 12 - 20MOQ: 2000 Square Meters -
4 Rib Height Expanded Metal High Rib Lath/rib Lath ManufacturerUS$ 2 - 3MOQ: 800 Pieces
-
Flat Rib LathUS$ 2 - 3MOQ: 800 Pieces
-
Professional Rib Lath/Expanded Metal Lath Used in ConstructionUS$ 2 - 3MOQ: 800 Pieces
-
High Rib Formwork/rib Mesh/ hy Rib Lath for SaleUS$ 2 - 3MOQ: 800 Pieces
Specifications
Conveyer Belt Mesh :1.SS 304 304L 316L
2.10-2800 mesh
3.wire gauge:BWG8-BWG26
4.factory price
302 304 304L 306 dutch weave Stainless Steel Conveyer Belt Mesh
1. dutch wire mesh Material:
SS302, SS304, SS304L, SS316, SS316L
2. dutch wire mesh Weave:
Plain Dutch Weave, Twill Dutch Weave and Reverse Dutch Weave.
3. dutch wire mesh weaving ways:
While the warp wires remain straight,the weft wires are plain woven to lie as close as possible against each other in a linen weave forming a dense strong material with small. irregular and twisting passageways that appear triangular when diagonally viewing the weave .
4. Mainly four types according to weaving patterns:
Wire Mesh Filter Cloth Dutch Plain Woven
Wire Mesh Filter Cloth Dutch Twill Woven
Wire Mesh Filter Cloth Reverse Dutch Woven
Wire Mesh Filter Cloth Five-Heddle Woven
5. Dutch weave wire mesh Performance:
Stainless steel wire mesh offers excellent acid resistance, alkaline resistance and heat resistance. Also high tensile strength and good antirust property.
6. Dutch weave wire mesh Packing:
Stainless Steel Wire Mesh is packed in rolls, wrapped with waterproof paper then covered with hessian-cloth. Special packing may be arranged if necessary.
7. Dutch weave wire mesh Uses:
Stainless Steel Wire Mesh is mainly used as screening and filtering materials in oil industry, chemical industry, electronics, grain, rubber and other industries.
Mesh |
Wire Dia. (MM) |
Material (AISI) |
12mesh x 64mesh |
0.58 x 0.40 |
304 or 316 |
24mesh x 110mesh |
0.36 x 0.25 |
304 or 316 |
14mesh x 88mesh |
0.50 x 0.33 |
304 or 316 |
30mesh x 150mesh |
0.23 x 0.18 |
304 or 316 |
40mesh x 200mesh |
0.18 x 0.13 |
304 or 316 |
50mesh x 250mesh |
0.14 x 0.11 |
304 or 316 |
80mesh x 700mesh |
0.10 x 0.08 |
304 or 316 |
165mesh x 800mesh |
0.071 x 0.040 |
304 or 316 |
165mesh x 1400mesh |
0.06 x 0.04 |
304 or 316 |
200mesh x 1800mesh |
0.05 x 0.032 |
304 or 316 |
825mesh x 2300mesh |
0.035 x 0.025 |
316L |
400mesh x 2800mesh |
0.030 x 0.02 |
316L |
4.Some pics:
if you have some questions,pls tell me ,it is my honor to help you.
Lisa
Skype:lisa41255
T:8613363876078
