Corrugated Iron Roofing Sheet Roll Forming Machine/ Corrugated Roof Tile Making Machinery
US$ 8,000 - 14,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Tile Forming Machine
Tile Type:
Colored Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Corrugated Metal Roofing Roll Forming MachineryUS$ 4,000 - 8,000MOQ: 1 Set -
Hebei Cangzhou Cold Bending MachineryUS$ 1,000 - 13,000MOQ: 1 Set
-
Hot Sale Condenser Roofing Sheet Steel Plate Bending MachineryUS$ 1,000 - 13,000MOQ: 1 Set
-
Hydraulic Press Brake Bending Machines Automatic Profile Bending MachineUS$ 1,000 - 13,000MOQ: 1 Set
-
High Quality Cnc Profile Bending MachineUS$ 1,000 - 13,000MOQ: 1 Set
Condition
New
Type
Tile Forming Machine
Tile Type
Colored Steel
Use
Roof
Production Capacity
8-12m/min
Place of Origin
Hebei, China
Brand Name
TY roll forming machine
Model Number
TY roll forming machine, TY corrugated roof roll forming machine
Power(W)
4+4KW
Voltage
4KW
Dimension(L*W*H)
6500*1500*1200
Weight
5.5T
Certification
ISO CE
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
Corrugated iron roofing sheet roll forming machine/ corrugated roof tile making machinery
Specification
Weight capacity of decoiler |
2.5T |
Appearance Size(L*W*H) |
6500*1500*1200 |
Raw material /feeding sheet material |
colored steel & galvanized steel |
Roller material |
45# high grade steel |
Shaft material |
45# high grade steel |
Kind of drive |
chain drive |
Cutting system |
automatic hydyaulic cutting |
Cutting blade material |
Cr 12 high grade steel |
Frame material |
300 H-high grade steel |
Control system |
totally automatic PLC control system |
Main power |
3 kw |
Roller stations |
13 rows |
Speed of production |
8-12m/min |
Thickness of colored steel |
0.2-0.8mm |
Frame material |
300 H-steel |
Product show
Roofing Sheet Roll Forming Machine has following advantages
- Forming machine rollers are manufactured from high quality bearing 45 # steel(not A3 steel), which make roller more wearable and longer life;
- Forming machine housing is manufactured from H steel(not angle iron),which the machine run in stable situation and avoid vibration to affect forming precision;
- The key components of PLC control system, electric switches, electric motors, drives and hydraulic componentsare famous brands to ensure the machines in good and stable working order for long time;
- Forming machine all parts with special treatment for anti-corrosion and long life(shaft chromeplated, straining beam galvanized ,screw rod black painted);
- Forming machine all parts baking finishing and then assembly
Roof and wall panel smples
FAQ
Q:How is this machine's service life?
- In the normal maintenance,the service life at least 8 years.
Q:How to maintenance?
- If using frequently,best coating lubricant on the chain and two ends of the shaft every month, replace the hydraulic oil every 1-2 years.
Q:What can you do if the machine broken?
- Our machine's warranty period is 1 year,if the broken parts can't repair, we can free send the new parts replace the broken parts to you;
Q:Can you supply the raw materials?
- Yes,we can supply the galvanized steel coil,galvalume steel coil,color steel coil,and aluminum coil.
