Help CenterCar Panel Roll Forming Machine/siding Panel Roll Forming Machine
Related Products
-
Carriage Plate Forming Machine/ Car Panel Roll Forming MachineUS$ 10,000 - 30,000MOQ: 1 Set -
Large-size Car Panel Roll Forming Machine Delivery PromptlyUS$ 6,500 - 20,000MOQ: 1 Set
-
1220 Container Board/panel Roll Forming MachineUS$ 10,000 - 30,000MOQ: 1 Set
-
Car Panel Custom Roll Forming MachineryUS$ 6,500 - 20,000MOQ: 1 Set
-
Car Panel Curving Cold Roll Forming MachineUS$ 6,500 - 20,000MOQ: 1 Set
Specifications
, roll former periodic maintenance;roll former easy replacement
the production of power fast for roll former
car panel roll forming machine
According to customer requirements ,custom roll forming machine
TY Car panel metal corrugated roll forming machine
1.Specification
| Dimensions | 10000*1300*1200mm |
| Kind of drive | Driving with 2.6 inch chain |
| Diameter of roller | 80mm |
| Rolling speed | 8m/min |
| Rolling thickness | 0.8-1.5mm |
| Roller station | 13 rows |
| Main power | 11kw with reducer |
| Large frame | 350H steel |
| Middle plate | 18 mm |
| Machine weight | 5T or so |
2.Automatic system(The PLC can be designed according to customers' requirement)
| Pump station | 4kw |
| PLC | Taiwan"Delta" |
| Transducer | Taiwan"Delta" |
| Encoder | Wuxi's"REP"or "XINYA" |
| Switch | "CHINT" or "DELIXI" |
3.The production process
| Decoiler→Flating→Feeding→Forming→Cut to length→Colletion(finish goods) |
4.Service
|
We provide the technical support for whole life. Meanwhile, if any parts go broken and not artificial damage, we will send you new ones for free. When need the technician to go abroad, we will arrange the technician. But the buyer should take all the cost, including Visa, Roundtrip ticket, suitable accommodation and pay the service fee to the technician with $100~150/days |
5.Payment
|
T/T( 30% by T/T in advance, the rest 70% to be payed by T/T after you inspect the machine in seller's factory before delivery ) |
6.About us
|
Our company have the series of coloured steel forming machine, including moding machine, concealed roof sheeet machine, flat sheet bending machine and so on |
|
Product Range
Full-automatic roof or wall panel roll forming machine Glazed tiles roll forming machine Double layer roll forming machine Specialized machine for Russian area Rolling shutter door machine Floor decking roll forming machine Roof ridge cap forming machine C/Z purlin roll forming machine Dust shield roll forming machine Van panel manufacturing machine Sandwich panel production line,etc
|
