Help CenterFZG -10 Vacuum Drying Oven/vacuum Dryer
Related Products
Principle of FZG -10 Vacuum Drying Oven/vacuum dryer:
It is well known that vacuum drying is to put raw material to the state of vacuum for heating and drying . if use vacuum to take air and humidity out, the dry speed will be faster.
Note: if use condenser, the solvent in raw material can be recovered. The condenser can be substituted by SK series water-ring vacuum pump or ZSWJ series hydropower spray vacuum pump unit if available.
Application of FZG -10 Vacuum Drying Oven/vacuum dryer:
It is Suitable for drying of thermal sensitive materials easily resolved. Polymerized or deteriorated under higher temperature and it is wide used in pharmaceutical, chemical, foodstuff and electronic industries.
Parameters of FZG -10 Vacuum Drying Oven/vacuum dryer:
parameter/model |
YZG-600φ×L |
YZG-1000φ×L
|
YZG-1400φ×L |
FZG-15L×W×H |
Inner size of syring chamber(mm) |
600×976 |
1000×1527 |
1400×2054 |
1500×1400×1220 |
Outer size of drying chamber(mm) |
1153×810×1020 |
1693×1190×1500 |
2386×1657×1920 |
1513×1924×2060 |
Layers of backing support |
4 |
6 |
8 |
8 |
interval(mm) |
81 |
102 |
102 |
122 |
Size of baking tray(mm) |
310×600×45 |
460×640×45 |
460×640×45 |
460×640×45 |
Quantity of baking tray |
4 |
12 |
32 |
32 |
Working pressure inside the pipe of baking support(MPa) |
≤0.784(8kg/cm2) |
≤0.784 |
≤0.784 |
≤0.784 |
Temperature inside the chamber(°C) |
≤150 |
≤150 |
≤150 |
≤150 |
Degree of vacuum inside the chamber when operation in idle, MPa |
≤30 |
|||
Under the vacuum condition of 30and110°C ,evaporation rate of water(kg/m2,h) |
7.2 |
|||
Model and power of vacuum pump when condenser is used(kw) |
2X-15A 2kw |
W3 5.5kw |
W3 7.5kw |
2X-70A 7.5kw |
Model and power of vacuum pump when condenser is not used(kw) |
SK-0.8 2.2kw |
SK-3 5.5kw |
SK-3 7.5kw |
SK-3 7.5kw |
Weight of drying chamber(kg) |
250 |
800 |
1000 |
2100 |
