Help CenterSmall Vacuum Tray Dryer
Related Products
Principle of Small Vacuum Tray Dryer:
It is well known that vacuum drying is to put raw material to the state of vacuum for heating and drying . if use vacuum to take air and humidity out, the dry speed will be faster.
Note: if use condenser, the solvent in raw material can be recovered. The condenser can be substituted by SK series water-ring vacuum pump or ZSWJ series hydropower spray vacuum pump unit if available.
Application of Small Vacuum Tray Dryer :
It is Suitable for drying of thermal sensitive materials easily resolved. Polymerized or deteriorated under higher temperature and it is wide used in pharmaceutical, chemical, foodstuff and electronic industries.
Parameters of Small Vacuum Tray Dryer:
parameter/model |
YZG-600φ×L |
YZG-1000φ×L
|
YZG-1400φ×L |
FZG-15L×W×H |
Inner size of syring chamber(mm) |
600×976 |
1000×1527 |
1400×2054 |
1500×1400×1220 |
Outer size of drying chamber(mm) |
1153×810×1020 |
1693×1190×1500 |
2386×1657×1920 |
1513×1924×2060 |
Layers of backing support |
4 |
6 |
8 |
8 |
interval(mm) |
81 |
102 |
102 |
122 |
Size of baking tray(mm) |
310×600×45 |
460×640×45 |
460×640×45 |
460×640×45 |
Quantity of baking tray |
4 |
12 |
32 |
32 |
Working pressure inside the pipe of baking support(MPa) |
≤0.784(8kg/cm2) |
≤0.784 |
≤0.784 |
≤0.784 |
Temperature inside the chamber(°C) |
≤150 |
≤150 |
≤150 |
≤150 |
Degree of vacuum inside the chamber when operation in idle, MPa |
≤30 |
|||
Under the vacuum condition of 30and110°C ,evaporation rate of water(kg/m2,h) |
7.2 |
|||
Model and power of vacuum pump when condenser is used(kw) |
2X-15A 2kw |
W3 5.5kw |
W3 7.5kw |
2X-70A 7.5kw |
Model and power of vacuum pump when condenser is not used(kw) |
SK-0.8 2.2kw |
SK-3 5.5kw |
SK-3 7.5kw |
SK-3 7.5kw |
Weight of drying chamber(kg) |
250 |
800 |
1000 |
2100 |
