Help CenterUL 1726 300V 150C High Quality Teflon Insulated Wire
Related Products
-
32AWG UL1708 200C Heat Resistant PFA Insulated WireUS$ 0.04 - 0.8MOQ: 2000 Meters -
UL1710 600V 200C PFA Teflon Coated Wire Resist Electrical WireUS$ 0.3 - 1MOQ: 2000 Meters
-
UL 1708 200C High Quality PFA Insulated WireUS$ 0.1 - 2MOQ: 2000 Meters
-
UL 1709 300V 200C High Quality PFA Insulated WireUS$ 0.1 - 2MOQ: 2000 Meters
-
UL1710 PFA Insulation 600V 200C Heat Resisitant WireUS$ 0.03 - 1MOQ: 2000 Meters
Specifications
UL 1726 300V 150C High Quality Teflon Insulated Wire1. High quality, low price
2. Professional OEM manufature
3. ISO,UL
UL 1726 300V 150C High Quality Teflon Insulated Wire
Product Features:
Rated Voltage: 300V
Rated temperature: -100deg. C~+150deg. C
O. D Tolerance: ± 0.10mm
Testing voltage: 2500V
Conductor: Nickel-coated, tin-coated and silver-coated copper wire
Insulator: PFA Teflon
Color: White-Black-Blue-Red-Yellow-Green-Brown-Transparen-Yellow/Green
Use: Lead wires for home electric appliances, lightings, electric equipment andsensrs etc.
Conductor |
Insulator |
Electrical Characteristic |
|||||||
AWG |
Conductor construction NO. Xφ mm |
Diameter mm |
Insulator Thick mm |
Over Diameter mm |
Resistance 20° C ohm/km |
Permissible ampactity 20° C-AMR |
|||
30 |
1*0.25 |
0.25 |
0.2 |
0.65 |
361.13 |
0.66 |
|||
28 |
1*0.31 |
0.31 |
0.25 |
0.81 |
227.39 |
1.05 |
|||
26 |
7*0.15 |
0.46 |
0.3 |
1.06 |
148.94 |
1.61 |
|||
19*0.10 |
0.5 |
0.3 |
1.1 |
148.94 |
1.61 |
||||
24 |
7*0.20 |
0.61 |
0.3 |
1.21 |
93.25 |
2.57 |
|||
19*0.12 |
0.6 |
0.3 |
1.2 |
93.25 |
2.57 |
||||
22 |
7*0.25 |
0.76 |
0.3 |
1.36 |
55 |
4.36 |
|||
19*0.15 |
0.76 |
0.3 |
1.36 |
55 |
4.36 |
||||
20 |
7*0.31 |
0.95 |
0.3 |
1.55 |
34.6 |
6.94 |
|||
19*0.19 |
0.96 |
0.3 |
1.56 |
34.6 |
6.94 |
||||
18 |
7*0.39 |
1.19 |
0.3 |
1.79 |
21.8 |
11.01 |
|||
19*0.235 |
1.18 |
0.3 |
1.78 |
21.8 |
11.01 |
||||
16 |
7*0.50 |
1.53 |
0.3 |
2.13 |
13.7 |
17.52 |
|||
19*0.30 |
1.51 |
0.3 |
2.11 |
13.7 |
17.52 |
||||
14 |
19*0.37 |
1.86 |
0.38 |
2.62 |
8.62 |
27.84 |
|||
12 |
19*0.46 |
2.32 |
0.4 |
3.12 |
5.43 |
44.2 |
|||
10 |
37*0.43 |
3.02 |
0.5 |
4.02 |
3.41 |
70.38 |
|||
Production Line
Certificates
Quality Control & Test Instruments
Factory Overlook
