Palm Oil Refinery Plant for Sale
- Tianjing/Qingdao
- T/T Credit Card
You May Like
-
Small Press Machine for Palm Fruit China Supplier
-
Palm Oil Refinery Machine Made in China
-
Palm Fruit Extraction Machine | Palm Oil Milling Machine
-
Palm Oil Extraction Machine | Palm Oil Milling Machine
-
Palm Kernel Expeller Machine | Palm Fruit Pressing Machine
-
Palm Fruit Processing Machine | Palm Kernel Processing Machine
Product Details
| Condition | New | Usage | Other, palm oil refining machine | |
| Type | Other, palm oil refining machine | Automatic Grade | Automatic | |
| Production Capacity | 100% | Place of Origin | Henan, China | |
| Brand Name | Doing, Yongle | Model Number | palm oil refining machine | |
| Voltage | 380V/220V | Power(W) | palm oil refining machine | |
| Dimension(L*W*H) | palm oil refining machine | Weight | palm oil refining machine | |
| Certification | CE, ISO | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
palm oil refinery plant for sale
The Introduction of the cude palm oil refining machine:
1.Introduction of palm oil refining machine:
(1) Purpose :Oil refining is using the physical methods and chemical processes to get rid of the harmful impurities and bed small in the crude oil.
Our oil refining machine is suitable for refining various crude vegetable oil, such as sunflower seed oil, tea seed oil, groundnut oil, cottonseed oil, palm oil, rice bran oil, soybean oil, corn oil and palm oil, etc.
(2) main parts:refining pot , decoloration pot ,deodorization pot , oil pumps and other parts
(3) Advantage: a .After refining the impurity of oil must be less than 0.2% ;
b.Recycling system save power and money ;
c.Lower oil waste.
2.Working process of oil refining machine:
Add acid or alkali to separate according to the acid value. After one hour's processing and 4-6hours deposit, then convey soap stock to storage tank.
(2)Pump refined oil into decoloring tank. When it is up to 90-110°C after one hour's heating, add clay into tank for 20min's processing. Then separate clay and oil with filter.
(3)Put discolored oil into deodorization tank with vacuum pump. Heat and process with steam for odor removal. After filtering, you will get final oil product.
3.Functions of main parts
(1) Refining section: used to P-acid de-gumming, alkali refining de-acid and water rinsing.
(2) Decoloring section: used to remove off pigments, bleaching oils and grease dehydrate.
(3) Deodorizing section: to remove off the odor components in oil.
(4) Dewax: used to remove off the wax in the oil, in order to get the high quality oil.
(5) Heat-transfer oil stove: supply each device production needing heat energy, temperature reach above 280°C.
(6) Steam generator: produce the needing steam for de-odoring and distillation.
(7) Vacuum pump: supply needing vacuum for dehydrate, de-color, de-odor. Vacuum degree can reach above 755mm Hg.
(8) Press filter: filter clay, filter out clear oil.
(9) Air compressor: blow dry bleached clay, blow empty the leftover oil in the press filter.
4.Professional Advice
Please kindly inform us your required daily capacity, treated quantity, raw material, covering space and related data.
Any question, welcome to contact us.
the specification of crude palm oil
Item | Standard |
Smell and taste | The original smell and taste of sunflower oil |
Moisture and volatile matter (%) ≤ | 0.20 |
Insoluble impurities (%) ≤ | 0.20 |
Acid value (mgKOH/g) ≤ | 4.0 |
Peroxide value (mmol/kg) ≤ | 7.5 |
the specification of refined palm oil
Item | Standard |
Color (Lovibond Cell 133.4mm) ≤ | R2.0 Y20 |
Smell and taste ≤ | No smell and good taste |
Transparence ≤ | Clear and transparent |
Moisture and volatile matter (%) ≤ | 0.05 |
Insoluble impurities (%) ≤ | 0.05 |
Acid value (mgKOH/g) ≤ | 0.20 |
Peroxide value (mmol/kg) ≤ | 5.0 |
Smoke point (°C) ≥ | 215 |
palm oil refining machine plant:
