Specifications
Design for non-pressure solar water heaterscontrol electric heater and make up water automatically.
CE certified,high quality
Non-Pressure Solar Water Heater Controller(SR500)
Main technical data
1. Appearance of controller: see product itself
( dimension: 210mm x145mm x48mm)
2. Power supply: A230V±10%
3. Power consumption: < 3W
4. Accuracy of temperature measuring: ± 2°C
5. Range of tank temperature measuring: 0 ~99°C
6. Range of temperature display: 0~ 99°C
7. Suitable power of pump: 2 pumps possible to be connected, power of each pump ≤600W
8. Suitable power of electrical booster: standard ≤2000W.
9. Ambient temperature: -10 °C ~ 50 °C.
10. Water proof grade: IP40.
11. Socket: choice by customer
Main function
1. Time display
2. Water temperature display
3. Water level display
4. Auto mode
5. Water level pre-set
6. Manual water loading
7. Temperature controlled water loading
8. Timing water loading
9. Water loading when tank is lack of water
10. Complusive water loading
11. Increasing Water pressure during water is loaded.
12. Manual heating
13. Timing heating
14. Hot water circulation
15. Low-pressure water loading
16. Low pressure protection
17. Collector tube protection
18. Memory protection when power is fault
