Energy saving lamp life test device
- 30 Set / Sets per Month
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Sunho | |
| Model Number | SH3302F | Power | Electronic | |
| Usage | Other |
Product Description
It is designed according to Chapter 12.1 relevant standard requirements of IEC60598.
Apply to ordinary light bulbs, energy-saving lamps and other screw-type lamp to do the life test. (Specifications can according to the user to design) can used it to do the on-off and other life test.
Technical parameters:
Power supply is AC220V±10% 50Hz
Test voltage is AC 50~250V, can be continue adjusted
Test total current:AC0.01A~30A
Current resolute rate:1mA
Test station:100, divided into at least 3 groups(The total power not exceed 5KW), the maximum power of the single test station is 30W.
Control mode:100 test stations, divided into at least 3 groups,the on and off time of each group can be set.
Each layer put through (power on )time: 0~99S99s~99H99s, stop time:0~99s99s~99H99s, can be set
Test time: 1~9999H, can be set
Test number:0~999999,can be set
Display mode: Touch screen+PLC
Translated and display the average age of the test sample in the touch screen
Provides each test sample power on or off test instructions, display the test voltage of each layer, switch and display the operating current of each routs.
Fault detection:Each test station with separate current monitoring device, to monitor the working status of each test sample, and feedback to the controller, then to record the start time, end time and the damage time.
Protection device: with leakage, short circuit protection functions
Test samples need to provide by the customer.
