110-250mm PVC Pipe Extrusion Line

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Pipe
Plastic Processed	PVC	Screw Design	Double-screw
Place of Origin	Jiangsu, China	Brand Name	PVC pipe extrusion line
Model Number	110-250	Voltage	380
Dimension(LWH)	30X6X5	Certification	ISO/CE
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

PVC Pipe Extrusion Line
Suitable to U-PVC,C-PVC,M-PVC pipe extrusion
Perfect synchronized
Lowest material consumption

A polyvinyl chloride (PVC) pipe is made from a plastic and vinyl combination material.

The pipes are durable, hard to damage, and long lasting.

A PVC pipe does not rust, rot, or wear over time. For that reason,

PVC piping is most commonly used in water systems, underground wiring, and sewer lines.

ProjectModel	GF-50	GF-110	GF-160	GF-250	GF-400	GF-630
Extruder	SJSZ-51	SJSZ-65	SJSZ-65	SJSZ-65	SJSZ-80	SJSZ-92
Pipe diameter range(mm)	16-40	50-110	63-160	110-250	200-400	315-630
Haul-off speed(m/min)	3-12	2-8	2-8	0.4-3	0.4-3	0.4-3
Total power(kw)	62	66	89	95	135	255
Total length(mm)	17000	18000	20000	20500	28000	30000

The complete extrusion line is developed with the 1990s advanced technology of West Europe by our company.

The main machine is SJSZ conical twin-screw extruder with cossponding downstream equipment..

Extruder

FHigh extrusion capacity, low melt temperature.

FSpecial screw design insure the high-efficiency and high yield

FBevel gear design of high hardness and low noise brings ependable performance with oong service life.

FAdoption direct current speed regulation design for the standard, also the frequency variable speed adjusting and the electromagnetism speed adjust may be chosen.

Die and Calibretor

¨ The sizing sleeve carries precooking equipment at its entrance is applicable to super-speed extrusion.

¨ On the front end of butterfly type sizing sleeve carrying entrance water curtain there is a closed inside room, which is applicable to the small diameter tube extrusion specially.

¨ Detained time on section of fluid divide body distributes even.

The vacuum water cooling tank

* The tank body made by stainless steel.

* Lengthways move by motor regulating.

* There-dimensional adjusting

* Have the high and low water level control device

* The water pump of high power and spraying head of special design bring high efficient spraying cooling.

Haul off device

² Double, three, four or six pedrails hauling machine

² Changing frequency speed adjusting system guarantee synchronous hauling off.

² By proportion valve and gas pressure control to regulate precisely contact pressure

² By the cenral motor drives all pedrail to attain highly synchronous result.

Cutting device

Have the set dimension and automatic cut function
Following cut and complete synchronous.
Low noise and high protection design.
