IML Label Slitting Rewinding Machine IML Slitter Rewinder
Main Parameters:
Model |
650 slitting machine |
1300 slitting machine |
1600 slitting machine |
Max Feeding Width ( mm ) |
650 |
1300 |
1600 |
Main Engineer Power ( kw ) |
3 |
6 |
6 |
Speed ( M/M ) |
80 |
120 |
120 |
Size ( mm ) |
2400*1700*1450 |
2400*2000*1300 |
2400*2300*1300 |
Weight ( kg ) |
1000 |
1200 |
1500 |
Rewinding Diameter ( mm ) |
600 |
800 |
800 |
Winding Diameter ( mm ) |
450 |
450 |
450 |
Precision ( mm ) |
±0.10 |
±0.10 |
±0.10 |
Power |
220V 50Hz |
380V 50HZ |
380V 50HZ |
Functional characteristics:
This is a high accuracy, high sensitivity slitting rewinding machine.
Air shafts are used for unwind or rewind.
Magnetic powder cluth or magnetic powder brake are used for adjust the tension
Straight blade or circle blade are available.
Imported rectification equipment is used for web guide.
Meter counter is availabel.
All the running roller are with special treatment to avoid scratch the material.
Characteristic: High slit accuracy, high slit speed, easier to operate or maintenance.
Purpose:
It is suitabel for slit industrial adhesive labels, tape, cellphone tape, protective film, copper foil, aluminum foil, OPP, PE, PVC, sheet, cloth, etc. This machine is widely used in the industries such as printing, packing, electronics, leather, clothes making, plastic, etc.
Videos:
http://youtu.be/7_Xu8w-CdSo slitting film
http://youtu.be/LLWreKH6dOM slitting the iml
