Asynchronous Neutral Labels Die Cutting Machine
Main Parameters:
Model |
MQ-320B |
Max Feeding Width(mm) |
320 |
Max Cutting Area(W*L) |
300*300 |
Max Cutting Speed(T/Min) |
200 |
Position Accuracy(mm) |
±0.10 |
Power Of Main Engine(kw) |
2.2 |
Size(L*W*H)(m) |
2.3*1.25*1.5 |
Voltage(V) |
380 |
Weight(kg) |
1500 |
Total Power(kw) |
4 |
Functional characteristics:
The machine body is cast on the whole, and the machine enjoys powerful pressure, stable operation, firm and durable. It contains an oil gear box which reduces abrasion to the machine during the operation, thus prolonging the life span of the machine, enhancing the utilization ratio the machine.
Scope applicable:
The product is developed aiming at the die cutting and forming of various insulating materials such as electric shield material, PVC, film, Mylar, copper foil, aluminum foil, foam, etc. in the electronic industry or printing industry.
