Help CenterDTSF1531 Multi Tariff Energy Meter
Related Products
-
Three Phase Multi-rate Energy MeterUS$ 10 - 30MOQ: 500 Pieces -
Multi-rate Energy MeterUS$ 10 - 30MOQ: 500 Pieces
-
DTSF1531 3 Phase 4 Wire Multi-function Industrial Kwh MeterUS$ 10 - 30MOQ: 500 Pieces
-
Single Phase Wireless Electricity MeterUS$ 10 - 12MOQ: 1000 Pieces
-
1P+N MCB/RCDUS$ 1 - 15MOQ: 100 Pieces
Specifications
1.easy use and install2.high quality and reasonable price
3.OEM offered
Application
DTSF1531/DSSF1531 three phase four wire electronic multi-tariff active energy meter,LCD display.
The meter is used to measure 50Hz or 60Hz active energy consumption from three phase four wire AC electricity net.
The meter adopts LSI (Large-scale Integration) and SMTmanufacturing technique,the key components and part all adopt long life type.
The meter is widely used in office buildings,shopping malls,residences,airports and metro,etc.
The meter measures consumption in different tariff in different time period.
Main Technical data
Item |
Model |
Rated Voltage (V) |
Rated Current (A) |
Accuracy |
Connection |
Three Phase Four Line Multi-rate Active Power Meter |
DTSF1531 |
3χ57.7/100V |
1.5(6), 3(6) |
1.0 or 2.0 |
Mutual induction |
1.5(6), 3(6), |
1.0 or 2.0 |
Mutual induction |
|||
3χ220/380V |
5(20), 10(40), 15(60), 20(80), 30(100) |
1.0 or 2.0 |
Direct |
||
Three Phase Four Line Multi-rate Active Power Meter |
DSSF1531 |
3χ380 |
1.5(6), 3(6) |
1.0 or 2.0 |
Mutual induction |
|
5(20), 10(40), 15(60) 20(80), 30(100) |
1.0 or 2.0 |
Direct |
|||
3χ100 |
1.5(6), 3(6) |
1.0 or 2.0 |
Mutual induction |
Function and Features
1. Each of hour periods has different rates (point period, peak period, smooth period and trough period). Every period of time
can be programmed into 12 periods of time and the minimum time interval is five minutes;
2. All the consumption date can be reserved for 12 months;
3. The meter adopts the advanced energy measuring chips, high capability CPU and RTC clock chips;
4. Recording the active electric quantity and the electric quantity under every rate, and reserve it;
5. High accuracy, sensitivity and reliability, wide overload endurance, low power consumption and light in weight;
6. Auto accumulate and recording the working time of the battery;
7. Communicate agreement accord with DL/T645-1997;
8. It has pulse output communication;
9. It adopts the password and program switch protection, recording the latest program time and degree;
