Specifications
High Speed Middle Bottom Sealing Bag-Making Machine1.Bag length:400mm
2.Bag with: 500mm
3.Speed: less than 45m/min
Specifications
High Speed Middle Bottom Sealing Bag-Making Machine
1.Bag length:400mm
2.Bag with: 500mm
3.Speed: less than 45m/min
High Speed Three Side Sealing Bag-Making Machine
-------------------------------------------------------------------------------------------------------------------------------------------------------------
Parameter
Material: BOPP, COPP, PET, PVC and Nylon, etc, plastic composite film, multi-layer co-extruded film, Aluminium composite film, paper-plastic film, pure aluminium foil composite film.
-------------------------------------------------------------------------------------------------------------------------------------------------------------
Function |
Three-side and center sealing |
Main electric component |
Main electric component drive two servo motor, main driver is AC motor with frequency. Unwinding constant tension.
|
Max Bag Beat |
150time/min |
Max. Feeding speed |
≤45m/min(depend on the material) |
Bag size |
Length: 400mm (Max 6 times feeding) Max. Width: 500mm |
Material size |
φ600×1050 mm (diameter & width) |
Positioning accuracy |
≤±0.5mm |
Qty of sealing knife |
Vertical sealing: 3 set upper and lower heating and cooling Horizontal sealing: 3 set upper and lower heating, 1 set upper and lower cooling Pressing: 2 set upper and lower heating and cooling |
Heating block qty |
16 |
Temperature setting range |
0-300°C |
Main power |
24kw (When start machine the power is about 33kw, when keep warm the power is about 8kw) |
Dimension |
11000×1500×1830mm |
Weight |
4.5T |
Surface |
Green and black |
Controller |
PLC |
