Open frame infrared touch 19 inch led 4:3 monitor for self-check machine
1. Robust and durable all-metal enclosure, dustproof and shockproof.
2. Industrial LCD panel, wide viewing angle, high nits, true color.
3. 4 wire resistive touch panel , high sensitive and fast-response.
4. High performance mainboard, 7x24 continuous operation.
5. Adopt HDMI 1.4 Digital decoding scheme, strong compatibility.
Model:SL19M | |
LCD panel | |
Panel size |
19" |
Standard Resolution |
1280*1024 |
Aspect ratio |
4:3 |
Support Color |
16.7M colors |
Backlight |
LED |
Brightness (cd/m²) |
500+ |
Response time |
5ms |
Contrast ratio |
1000:1 |
View angle |
Horizontal:170° ,(R/L 85°/85°) |
Vertical:160° ,(U/D 80°/80°) | |
Touch panel | |
Touch panel type |
2-points infrared touch panel ( 4-points , 6-points optional ) |
Tempered glass |
Thickness: 3mm, customizable |
Mohs hardness: 6.5 | |
Luminousness: up to 95% | |
Interface |
USB (RS232 optional) |
Touch response time |
10ms |
Working Life |
Unlimited |
Touch options |
(4 or 5 wires resistive touch,SAW, PCAP touch optional) |
Monitor | |
Signal ports |
VGA , HDMI, DVI |
Audio |
Speakers optional |
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select etc. |
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese etc. |
Support OS |
Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android ect. |
External Power Supply |
AC 100 - 240V |
Working voltage |
DC 12V |
Power consumption |
≤26W |
Temperature Range |
operating: -10 to 60°C, storage :-20 to 70°C |
Relative humidity |
operating: 10% to 90% , storage :5% to 90% |
Color |
Black, white, color can be customized |
Net weight |
6.3 kg |
Gross weight |
8.8kg |
Dimension |
30.6×46.1×4.6cm |
Packing size |
42.2×58.1×12cm |
Accessories |
Power adapter, HDMI /VGA/DVI cable, USB touch cable, touch pen |
Mounting (options) |
1) provide wall brackets for wall-mounting, VESA 100*100mm, 200*200mm |
2) provide stable metal holder to support the monitor | |
Certification |
CE, FCC, ROHS |
Warranty |
1 year warranty and 3 years free maintenance |
Why choose Shinho Electronic for LCD equipments?
