Model 250 hanging conveyor part list
Model: 250 part list:
N0. |
Parameter |
Name |
Quantity |
Unit |
Remark |
1 |
|
Hanging chain |
53 |
meter |
|
2 |
|
Straight rail |
42 |
meter |
6 meters a piece |
3 |
1.5Kw |
Electrical drive unit |
1 |
set |
Frequency control of motor speed |
4 |
R2000 |
Tension bridle |
1 |
set |
Weight block |
5 |
R2000*180 |
Bend rail |
1 |
piece |
|
6 |
|
Connect piece |
30 |
piece |
|
7 |
|
Temperature telescopic rail |
2 |
piece |
|
8 |
|
lubrication system( Mamual lubrication cup) |
1 |
set |
|
9 |
|
Hanging tool |
106 |
piece |
|
10 |
|
C type hanging tool |
106 |
piece |
|
11 |
|
Frequency conversion electronic control box |
1 |
set |
|
Hanging chain( 53 meters)
Parameters
MODEL |
250 |
Chain pitch(mm) |
250 |
Single point hoisting (kg) |
50 |
Chain allowable tension(KN) |
5 |
Chain breaking force(KN) |
<50 |
Chain weight(kg/m) |
10.5 |
Orbit weight(kg/m) |
8.12 |
Chain pitch(mm) |
120 |
Chain plate thickness(mm) |
16 |
Roller diameter(mm) |
66 |
Pin shaft diameter(mm) |
10.5 |
Reduction ratio |
1:10 |
Movement speed(m/min) |
0.2-2 0.28-2.8 0.41-4.1 0.56-5.6 0.7-7 0.97-9.7 |
Working temperature |
-20-200 |
Conveyor power(KW) |
1.5, 2.2 |
Straight rail( 42 meters)
Electrical drive unit (1 set)
Tension bridle (1 set)
Bend rail(1 set)
Connect piece(30 pieces)
Temperature telescopic rail (2 sets)
lubrication system( Mamual lubrication cup) (1 set)
check rail
( Mamual lubrication cup) (1 set)
Automatic lubrication system(optional)
Hanging tool (106 pieces)
C type hanging tool (106 pieces)
Frequency conversion electronic control box (1 set)
