Help CenterLeadingtouch 17" IP65 Panel Mount IR Multi-Touch Touch Monitor TM-1729
Related Products
-
Leadingtouch 17" Panel Mount Infrared IR Touch Monitor for Kiosks TM-1729US$ 200 - 400MOQ: 1 Unit -
LeadingTouch 55" Multitouch IR Touch Open Frame Touch MonitorUS$ 1,000 - 2,000MOQ: 1 Unit
-
Leadingtouch 55" Touch Kiosks MonitorNegotiableMOQ: 1 Unit
-
Leadingtouch Touch Monitor for Kiosks 12"-22"US$ 150 - 300MOQ: 1 Unit
-
Leadingtouch Kiosks Touch Monitor Kiosks TM-2469US$ 300 - 400MOQ: 1 Unit
Specifications
1,IR multi-touch waterproof kiosks touch monitor;2,DVI,VGA video input,Dual rs232 and USB touch controller
3,IP65 open frame
Agency Approval:Leadingtouch touchscreens, controllers, and cables have been approved for CE marking. Where appropriate, Touchmonitors are marked CE compliant, and are typically Class B. Systems incorporating leadingtouch touchscreens, controllers, and cables have been approved to FCC Class A compliance. Touchmonitors typically are FCC Class B verified RoHS
Model |
TM-1728-G312U8 Multitouch |
Description |
17″TFT Rear Mount Touchmonitor |
Case/Bezel Color |
Black |
Display |
4:3 Ratio Active matrix TFT LCD |
Optimal(native) resolution |
1280X1024@60Hz |
Sychronization Range |
Horizontal:30-80 kHz; Vertical: 60-75Hz |
Useful screen area |
Horizontal: 13.3" (338 mm);Vertical: 10.6" (270.3 mm) |
Colors |
16.7 million |
Brightness |
LCD panel: 300cd/m2 (typical) |
with touchscreen: 230 cd/m2 (typical) | |
With Leadingtouch Infrared touchscreen: 280 cd/m2 (typical) | |
Pixel Pitch |
0.264 x 0.264 mm |
Response Time |
8 msec (typical) |
Contrast ratio |
500:1 typical |
Viewing angle(typical, from center) |
Horizontal (left/right): 140°(70° /70° ) |
Vertical (up/down): 130°(70° /60° ) | |
Backlight Lamp life |
50,000 Hrs to 1/2 brightness |
Input video format |
VGA or DVI optional |
Input video signal connector |
Mini D-Sub 15-Pin VGA type |
On Screen Display(OSD) |
Remote OSD with 1.2m cable |
Touch Technology |
Multitouch Infraed Touch Panel |
Touch Interface |
RS23 or USB |
Touch Resistive Time |
10ms |
Mounting Options |
Rear Fixed, 75 mm & 100mm VESA mount |
Power supply |
External:100-240V AC, 50-60 Hz |
Power Consumption |
50W max |
Temperature Range |
Operating: 0°C to 50°C; Storage: -20°C to 60°C |
Humidity Range |
Operating: 10%-90%; Storage: 5%-90% no condensing |
Touchmonitor Dimension |
368x 306 x 48(mm) |
Shipping Carton Dimension |
460x 409 x 175(mm) |
Weight(approx.) |
Monitor: 3.8kg / shipping: 6kg |
Warranty |
1 year |
Agency Approvals |
FCC, CE, CCC,RoHS compliant |
