Specifications
1,IP65 Infrared touch screen monitor2,Support multi-touch application
Agency Approval:Leadingtouch touchscreens, controllers, and cables have been approved for CE marking. Where appropriate, Touchmonitors are marked CE compliant, and are typically Class B. Systems incorporating leadingtouch touchscreens, controllers, and cables have been approved to FCC Class A compliance. Touchmonitors typically are FCC Class B verified RoHS
Leadingtouch 17" Open Frame IR Infrared Touch Screen Touch Monitor
TM-1728 is a customized rear and side mountable flat panel LCD monitor with the flexibility to integrate touch technologies IP65 Infrared touchscreens. These TM series LCD monitors provided you with premium quality in optical resolution, durability and stability. Built with watertight IP65 rated front bezel, this unit becomes completely dust and waterproof. These could also withstand various public and weather conditions
Model |
TM-1728 |
Description |
17″TFT Open Frame Touchmonitor |
Case/Bezel Color |
Black |
Display |
4:3 Ratio Active matrix TFT LCD |
Optimal(native) resolution |
1280X1024@60Hz |
Sychronization Range |
Horizontal:30-80 kHz; Vertical: 60-75Hz |
Useful screen area |
Horizontal: 13.39" (340 mm);Vertical: 10.75" (273 mm) |
Colors |
16.7 million |
Brightness |
LCD panel: 300cd/m2 (typical) |
| |
With IR Infrared touchscreen: 280 cd/m2 (typical) | |
Pixel Pitch |
0.264 x 0.264 mm |
Response Time |
8 msec (typical) |
Contrast ratio |
500:1 typical |
Viewing angle(typical, from center) |
Horizontal (left/right): 140°(70° /70° ) |
Vertical (up/down): 130°(70° /60° ) | |
Backlight Lamp life |
50,000 Hrs to 1/2 brightness |
Input video format |
VGA or DVI optional |
Input video signal connector |
Mini D-Sub 15-Pin VGA type |
On Screen Display(OSD) |
Remote OSD with 1.2m cable |
Touch Technology |
IR Infrared Touch Panel |
Touch Interface |
Combo 10ms232 and USB interface |
Touch Resistive Time |
10ms |
Mounting Options |
Rear Fixed, 75 mm & 100mm VESA mount |
Power supply |
External:100-240V AC, 50-60 Hz |
Power Consumption |
50W max |
Temperature Range |
Operating: 0°C to 50°C; Storage: -20°C to 60°C |
Humidity Range |
Operating: 10%-90%; Storage: 5%-90% no condensing |
Touchmonitor Dimension |
474x 321 x 69.8(mm) |
Shipping Carton Dimension |
TBD |
Weight(approx.) |
Monitor: 4kg / shipping: 6kg |
Warranty |
Monitor: 3 years/’; LCD Panel: 1 year |
Agency Approvals |
FCC, CE, RoHS compliant |
