Intel ATOM D2550 MINI ITX Mini Industrial Motherboard Dual NIC Support GPIO
US$ 1 - 2
MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Desktop
Brand Name:
Other
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AMD APU E350 Support Ultrathin 12V MINI PCIE MSATA DVIUS$ 1 - 2MOQ: 1 Piece -
NM70I-847 Celeron 847 HD HDMI Mini ITX Mini MotherboardUS$ 1 - 2MOQ: 1 Piece
-
Ultra-thin ATOM Atom D525 Motherboard Dual MINI-PCIE One Machine Industry ITX MotherboardUS$ 1 - 2MOQ: 1 Piece
-
ROS the Soft Route Firewalls Motherboard With GPIO Industrial Motherboard / MINI-ITX ATOM N270 Dual Network PortUS$ 1 - 2MOQ: 1 Piece
-
Special 3.5 Inch Fanless ATOM N2600 CPU Car IPC Mini HD Computer Motherboard Dual NetworkUS$ 1 - 2MOQ: 1 Piece
Products Status
Stock
Application
Desktop
Brand Name
Other
Model Number
D2550
Specifications
Intel ATOM D2550 MINI ITX mini industrial motherboard Dual NIC support GPIOIntel ATOM D2550 MINI ITX mini industrial motherboard Dual NIC support GPIO
Intel RATOM D2500/D2550 processor
Intel RATOM D2500/D2550 + NM10 chipset
Built-in graphics core of the Intel RGMA 3600/3650
Support VGA |, DVI, HDMI asynchronous dual display
The integrated ALC662 6-channel sound card
Integrated LVDS support 24bit single channel TTT LCD
Onboard Dual LAN
Support GPIO
Support MINI-SATA SSD
MINI-ITX size (170mm * 170mm)
Motherboard Specifications
· Processor
· Intel RATOM D2500/D2550 processor (1.86G motherboard, 800MHz FSB, 1M / tertiary cache)
· Chip
· Intel RATOM D2500/D2550 + NM10 chipset
· Memory
· 1 * notebook DDR3 memory support up to 4GB
· Power
· ATX power supply
· Storage
· 2 * Serial II ATA interface, support for 3Gb / s; 1 * MINI-SATA interface
· Network
Onboard 2 * RTL 8105EL 100 BaseT LAN, support RTL and PXE diskless boot
· Sound
· Realtek ALC662 chip to provide 6-channel sound card
· LVDS
· Integrated LVDS support 24bit single channel TTT LCD
· USB
· Built-in 8 * USB 2.0
· Backplane interface
· 1 * PS / 2 · 1 * DVI (dual display support asynchronous) 1 * VGA (dual display support asynchronous)
· 1 * HDMI (supports asynchronous dual display) · 1 * COM port
· 1 * RJ-45 port, 4 * USB 2.0 port, 1 * audio input and output ports
· Built-in interface
· 2 * USB connectors support four USB ports
· 1 * VGA pins
· 1 * 4PIN powered seat
· 3 * fan connectors
· 1 * COM pins
· 1 * LVDS pins
· 1 * MINI-SATA interface
· 1 * GPIO
· BIOS
· AMI BIOS, ACPI supported, support calls boot function
· Temperature
· Work :0-60 degrees Celsius · Storage: -20 to 80 degrees Celsius and humidity: 10% to 90%
· Plate
· MINI-ITX (170mm * 170mm)
