ITX APU E240 Advertising ALL IN ONE PC Ultra-thin 3G Module 12V DC Input HDMI
US$ 1 - 2
MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Desktop
Model Number:
E240
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
INTEL D2700 ATOM 5COM Dual 8 LVDS Outdoor Advertising ALL-IN-ONE pc Industrial ControlUS$ 1 - 2MOQ: 1 Piece -
1U Ultra-quiet 775 All-copper Heat Sink Buffalo S0203S0204 S0205 1U ServerUS$ 1 - 2MOQ: 1 Piece
-
ASL Intel ATOM D2550 Motherboard Dual NIC 6COM Gigabit Soft Routing Board MINI ITXUS$ 1 - 2MOQ: 1 Piece
-
4 DVI-I Multi-screen Multi-graphics Motherboard MINI ITX AMD APU R Series With DC Power 4SATA2COMUS$ 1 - 2MOQ: 1 Piece
-
AD2700B-ITX Motherboard ATOM D2550US$ 1 - 2MOQ: 1 Piece
Products Status
Stock
Application
Desktop
Model Number
E240
Place of Origin
Guangdong, China
Specifications
ITX APU E240 advertising ALL IN ONE PC ultra-thin 3G module 12V DC input HDMIITX APU E240 advertising ALL IN ONE PC ultra-thin 3G module 12V DC input HDMI
AMD APU features
Ultra-low power consumption: DC IN/4PIN ATX power input, the average power consumption of only 30W
Mini Almighty: highly integrated onboard CPU and graphics card, small size
Digital HD: HDMI + SPDIF/1080P FULL HD
High scalability: * MINI-PCIE support WIFI wireless network card, a support SSD Solid State Drive
Onboard memory: exclusive onboard 512M capacity memory, more graphics / HD performance
Luxury materials: polymer Tanzania capacitors, chip inductors, low temperature MOS tube
Specifications
AMD E-240 1.4GHz dual-core processor
Chipset
AMD Hudson D1 chipset
Graphics
Integrated ATI Radeon HD6300 graphics core
Memory
1 * 204-pin single-channel DDR3 1333/800/667 memory, up to 2GB
Expansion slots
2 * PCIEx1 slot wireless WIFI and MSATA of interface, which can be accessed
Storage capabilities
2 * Serial ATA2 3Gb / s controller (the one column with MSATA total)
Audio features
Realtek ALC662 6-channel high-fidelity audio
Network functions
1 * RTL8111DL Gigabit LAN
Supports Wake on LAN
Backplane I / O interface
1 * 1 * HDMI Interface
1 * VGA Interface (DVI interface optional, and can not be used simultaneously with the HDMI interface)
2 * USB 2.0 interface (supports 4 USB devices)
1 * RJ-45 cable interface
1 * Audio I / O interface (Line Out) green interface
1 * Audio I / O interface (Mic red interface)
1 * 12V DC_JACK input
Built-in I / O interface
1 * 4p power seat (do input and output +12 V power connector)
2 * fan connectors;
2 * RS232 connector
1 * VGA 2 * 5 interface
2 * 15p single 24BIT LVDS interface (optional)
3 * USB 2.0 interface
1 * GPIO interface / 1 * CIR interface
1 * 4 amplifier interface can be plugged directly into the speaker output
* Audio connector (2 * 5 pumping 8)
BIOS
AMI 8MB DPI Flash ROM
Product Size
Mini ITX Form Factor (17cmx17cm)
