SHANTUI SD 32 Bulldozer
| ITEM | UNIT | SD32 |
|---|---|---|
| L×W×H (Ripper not included) | mm | 6880×4130×3725 |
| Operating weight (Ripper not included) | t | 37.2 |
| Engine | - | CumminsNTA855-C360S10 |
| Rated power | kW/rpm | 235/2000 |
| Gradeability | ° | 30 |
| Blade type | - | Straight tilt bladeSemi-U bladeAngle blade |
| Blade width | mm | Straight tilt blade 4130×1590Semi-U blade 4030×1720Angle blade 5000×1140 |
| Dozing capacity | m3 | Straight tilt blade 10Semi-U blade 11.9Angle blade 6 |
| Ma× drop below ground of blade | mm | 560 |
| Lift height of blade | mm | 1560 |
| Ripper type | - | Single ripperThree-shank ripper |
| Ripping depth of ripper | mm | Single ripper 1250Three-shank ripper 842 |
| Lifting height of ripper | mm | Single ripper 955Three-shank ripper 883 |
| Number of carriers (each side) | - | 2 |
| Number of track rollers (each side) | - | 7 |
| Number of track shoes (each side) | - | 41 |
| Width of track shoe | mm | 560 |
| Track gauge | mm | 2140 |
| Ground length and ground pressure | mm/MPa | 3150-0.105 |
| Pitch | mm | 228.6 |
| Forward speed | km/h | 0–3.6 |
| 0–6.6 | ||
| 0–11.5 | ||
| Reverse speed | km/h | 0–4.4 |
| 0–7.8 | ||
| 0–13.5 |
We are experts in SHANTUI bulldozer and excavator spare parts!
We are professioner manufacturer of bulldozer and excavator undercarriage parts!
More Competitive Parts:
1. Engine Related Parts (Radiator, Fan, Power take-off)
2. Torque Converter (Turbine Pump, Stator, Gear, Relief Valve)
3. Transmission Parts (Carrier, Friction, Plate, Shaft)
4. Steering System Parts (Steering clutch, Spiral bevel, Steering valve)
5. Final Drive Parts (Pinion, Sprocket Hub, Drum, Bearing)
6. Undercarriage Parts (Track shoe, Track link, Track roller, Carrier Roller, Track Shoe Ass’y)
7. Cylinders System (Blade Lifting Cylinder, Tilt Cylinder, Ripper Oil Cylinder, Hose, Tube)
8. Pump: Transmission Pump, Scavenging Pump, Hydraulic Pump, Steering Pump
9. GET Parts (Cutting Edge, End Bit, Tooth Tip, Shank, Guard Plate)
10. Engine Parts (WEICHAI POWER, SHANGHAI DIESEL)
Our company is Hainan PengSheng Industry Co,.Ltd.
We has specialized in heavy construction equipment for ten years with the principle of "Good quality, the best services, reasonable prices", and we are a manufacture factory of bulldozer and excavator undercarriage in china.
We have advantages on :
1) Bulldozer and excavator undercarriage manufacture factory.
2) All kinds of Shantui SD13,SD16,SD22,SD23,SD32,SD42 bulldozer parts.
3) All kinds of HBXG Shehwa SD7, SD8, TY140, TY165 bulldozer parts.
4) All parts for bulldozer D60,D65,D80,D85,D155,D355.
5) Liugong loader spare parts.
6) Track shoe and track link for Shantui, Hitachi, Doosan
7) NTA-855 engine, transmission, main pump, final drive, swing motor, etc.
8) Excavator spare parts PC60, PC130, PC200, PC220, PC300, PC360, PC400, PC450.
9) N, K, M, B and C series engine ass'y and engine parts.
Service commitment
- We will send the goods as fast as we can to save your time.
- All the pictures on our web site are real images of the part itself. What you see is what you get.
- Goods will be packed safely and carefully
Warranty
Q: There are so many suppliers from China, how to identify the quality?
A: All parts that we sell enjoy 3 to 12 months warranty; if any parts breaks during warranty, just offer us the proof. We'll resend you new one!
Delivery
Q: What if parts we order from you are lost during delivery?
A: We'll resend the parts!
Price
Q: Why your price is so high?
A: You get what you pay for.
There is no winfall profits at all in the open market. We just insist resonable profits.
We offer genuine parts and replacement parts as your request.
Lead time
Q: How many days it takes before you deliver the goods to us?
A: We have most easily-damaged parts in stock, for small goods, we could deliver you the goods after order confirmation and receving the payment; for large quantity, we need 1 or 2 more days to order wooden box or pallet, 2-3 days to book flight/vessel and deliver the goods to named port/airport.
About us
We have been in construction machinery field since 2005;
Excellent exhibitor of many famous exhibitions all over the world, CTT2012, ANKOK 2012, EXPO 2011 etc..
If you need the product, pls advise your machine brand & model, or offer the Part NO. Thank you!
Means of transport: by sea/by train/by air
Export standard packing (water proof,damp proof and mould proof), and can be customized.
Payment terms: 100%T/T or Western Union before shipment
Contact Person: Maxim
TEL:86-898-88597287
Skype: hpsi02
