Good Permeability Air Oil Separator Element

US$ 1 - 50 MOQ: 10 Pieces

Key Specifications

Place of Origin:

Henan, China

Brand Name:

D.K

Model Number:

LQLX&KLX

Xinxiang D.king Industry Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name D.K

Model Number LQLX&KLX

After-sales Service Provided Overseas service center available

Specifications

Air Oil Separator Element
1)polypropylene material to ensure high efficient
2) We can product by customers need
3)ISO-9001

Specifications

1, Air Oil Separator Element

KLX series filter, OLX series filters, other Filters;

2,Application:

air separation; purification of dust

3,Feature:

high efficiency; low resistance; good permeability; high reliability; long life and so on

3,Material:

kapok fiber or polyester

4,Application area:

blast furnace; blower air machine; gas turbine; diesel engine; central air conditioning system; central and other powder coating system

5,Detailed description:

Air Oil Separator Element

Name	Model	Air flow (m3/h)	Resistance (Pa)	Temperature (°C)	Efficiency (%)	Size(mm)
Name	Model	Air flow (m3/h)	Resistance (Pa)	Temperature (°C)	Efficiency (%)	L1	L2	H
Low-efficiency Panel filter	LQLX-600	600	30	80	≥45	290	290	38
	LQLX-1000	1000				290	493	38
	LQLX-1200	1200				290	595	38
	LQLX-1800	1800				493	493	38
	LQLX-2300	2300				493	595	38
Medium-efficiency Panel filter	LQLX-600	600	50~80		≥80	290	290	38
	LQLX-1000	1000				290	493	38
	LQLX-1200	1200				290	595	38
	LQLX-1800	1800				493	493	38
	LQLX-2300	2300				493	295	38
High-efficiency Panel filter	LQLX-350	350	200		≥99.9	290	290	220
	LQLX-500	500				320	320
	LQLX-1000	1000				484	484
	LQLX-1500	1500				595	595
	LQLX-2000	2000				960	484

Air Oil Separator Element

Model	Air flow (m3/h)	Resistance (Pa)	Temperature (°C)	Efficiency (%)	Size(mm)
Model	Air flow (m3/h)	Resistance (Pa)	Temperature (°C)	Efficiency (%)	D	DL	L
KLX-850	850	125~175	Bombax cotton: 105 Polyester fibre: 135	Bombax cotton: 99 Polyester fibre: 99.99 (≥2um)	φ320	φ212	φ560
KLX-900	900				φ320	φ212	φ610
KLX-1000	1000				φ320	φ212	φ660
KLX-1050	1050				φ320	φ212	φ700
KLX-1100	1100				φ350	φ240	φ600
KLX-1150	1150				φ350	φ240	φ650
KLX-1200	1200				φ350	φ240	φ710
KLX-1800	1800				φ400	φ291	φ915
