Help CenterPiping Prefabrication Automatic Welding Workstation(A Type)
Related Products
-
Piping Prefabrication Automatic Welding Workstation(C Type)NegotiableMOQ: 1 Set -
Piping Prefabrication Automatic Welding Workstation(B Type)NegotiableMOQ: 1 Set
-
Pipe Cutting and Beveling Workstation(Container Type)NegotiableMOQ: 1 Set
-
Piping Prefabrication Automatic Welding Workstation(D Type)NegotiableMOQ: 1 Set
-
PIPING AUTOMATIC WELDING WORK STATION;PIPE WELDING MACHINE FOR PIPE FABRICATION;AUTOMATIC WELDING MACHINE FOR STEELPIPE (A-TYPE)NegotiableMOQ: 1 Set
Specifications
1.High Productivity2.Reduce labor intensity
3.High automation level
4.High safety
5.ISO9001:2008
Detailed Product Description
CAPACITY: 450~650" per day
ELBOW,FLANGE AND PIPE BUTT WELD
Performance features
Basic structures: one 6m container made with special technology, 2 Piping Prefabrication Automatic Welding Machine, 2 Auxiliary Trolleys for Automatic Welding Machine, 2 Piping Cantilever Cranes and 2 FCAW/GMAW Welding Machines.
Production Efficiency: 450650 inch per day (DN200 SCH40) (higher efficiency will be achieved by using Piping Cantilever Cranes and Piping Prefabrication Automatic Welding Machine, but the efficiency will be lower when using the traveling cane for the fixed pipe prefabrication line).
Mobility: Excellent (without limitation of radiation radius when using container as carrier)
Application: Used in projects with a majority of common pipelines and few thick ones.
Technical parameters
Pipe diameter applicable: DN50-600(φ60-610)
Pipe wall thickness applicable: 3-60MM
Materials applicable: carbon steel, alloy steel, stainless steel and cryogenic steel
Welding line applicable: various welding lines of tubesections such as tube-tube, tube-elbow, tube-flange, flange-flange and flange-elbow, etc.-
Auto-welding covering rate: ≥60%
Pipe prefabrication depth: 50%~80%
Design of the detailed fabrication drawing: with PDSOFT 3DPiping, a software product specially used for designing pipe prefabrication.
Management of the prefabrication process: with PDSOFT PPMIS, management system software for pipe prefabrication and installation.
PIPING AUTOMATIC WELDING WORK STATION;PIPE WELDING MACHINE FOR PIPE FABRICATION;AUTOMATIC WELDING MACHINE FOR STEELPIPE (A-TYPE)
