RQL- A600/700/800 Hot cutting &Edge sealing bag making machine
Usage:
This machine is suitable for making clothing bag, Sock bag ,Towel bag , Jewelry bag , Underwear bag, Stationery bag , Electrical components bag, Bamboo & wood products bag, etc.
Suitable Material:
Suitable for BOPP. PP. PE. Heat shrinkable film. etc material can heating-sealing.
Features:
This machine is match for general BOPP, OPP bag production, and opener for PP, PE roll materials, bag making, production mode has variety of opening: flat mouth, envelope, flanging mouth, pillowcase mouth and so on, with automatic folding membrane, automatic stick gum, folder lining pearlized film, automatic pressure fluid, automatic punching . it's ideal equipment to making socks bags, towel bag, bread bags, jewelry bags.
TECHNICALPARAMETERS:
1.With elevated breach, imported conveyor belt .
2.The feeding adopts photoelectric control, colored light magic eye from Germany
3.Adopting PLC programming device, 5.7 inch computer control touch screen.
4.Servo motor to pull material in, adopt YASKAWA servo motor.
5..Main motor,front feeding motor,back receiving motor adopt Frequency control.
6.NSK Bearing , Siemens LDPE HDPE , Schneider Electric Switch.
7.Delivery by arrangement bearing , make the minimal hot cutting length to 40mm ,RQL-400A’s minimal hot cutting length attain to 16-25mm.
8.Ultrasonic wave Knurling device
MODEL |
RQL-A600 |
RQL-A700 |
RQL-A800 |
HOT CUTTING LENGTH |
40-999mm |
40-999mm |
40-999mm |
HOT CUTTING WIDTH |
580mm |
680mm |
780mm |
BAG MAKING SPEED |
40-240pc/min |
40-240pc/min |
40-240pc/min |
POWER |
3KW |
5KW |
7KW |
WEIGHT |
700KG |
800KG |
900KG |
SIZE |
3700X1200X1700mm |
3700X1400X1700mm |
3700X1600X1700mm |
Sock Bag Made By This Machine
