Specifications
Tektronix-DSA71604B Digital Serial Analyzer, 16GHz 4CHThe DPO/DSA/MSO70000 Series oscilloscope delivers exceptional signal acquisition performance and analysis capability. Discover your real signals with uncompromised acquisition on all 4 channels and capture more signal details with the industry's highest waveform capture capability. Automate setup, acquisition and analysis of high-speed serial data signals with a toolset engineered to deliver faster design and compliance testing.
- On All Four Channels Simultaneously
-20, 16, 12.5, 8, 6, and 4 GHz Bandwidth Models
-Up to 50 GS/s Real-Time Sample Rate
-Up to 250 Megasamples Record Length with MultiView Zoom™ Feature for Quick Navigation
- Fastest Waveform Capture Rate with >300,000 wfms/s Maximum per Channel
- Highest Bandwidth – Up to 20 GHz enables measurement on the latest high-speed serial standards
- Superior Signal Integrity and Excellent Signal-to-Noise Ratio – Observe the truest representation of your waveform
- Pinpoint® Triggering – Minimize time spent trying to acquire problem signals for efficient troubleshooting and shortened debug time
- 5 Gbps Real-time Serial Trigger – Assures triggering on the first instance of a specified NRZ or 8b/10b pattern to allow isolation of pattern dependent effects
- Search & Mark – Provides waveform pattern matching and software triggers for signals of interest
- DPX and Fast Acquisition - Quickly find intermittent events with the industry’s highest waveform capture rate
- Long Record Lengths – Capture long-term trends or infrequent events then analyze the entire acquired record with built-in measurements
- Application Support – Enables standard-specific certification, measurement automation, and ease of use
- Serial Data Link Analysis (SDLA) - For high-speed serial data streams, emulate and equalize the channel as well as de-embedding the fixture.
Purchase Includes:
- Wrist Strap
- Mouse
- Keyboard
- 4x Tek TCA-292MM
- Tek TCA-BNC
- Display Adapter
- Book Manual
- Accessory Case
