Home > Instruments & Meters > Test Instrument > Test Machine > NEW Agilent Keysight HP N9912A -104 FieldFox Handheld RF Combination Analyzer
NEW Agilent Keysight HP N9912A -104 FieldFox Handheld RF Combination Analyzer
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Keysight / Agilent
Model Number:
N9912A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Agilent / HP 8921A w/ 83201A Option 020 & 4M Memory Cell Site Test SetUS$ 3,800 - 4,800MOQ: 1 Unit -
Agilent/HP 6675A-J06 135V 16A 2160 Watt Power SupplyUS$ 4,800 - 5,300MOQ: 1 Unit
-
Acterna / Willtek 4359-1x 4353 CDMA Mobile Fault FinderUS$ 750 - 825MOQ: 1 Unit
-
Agilent / HP16047A Axial and Radial Test FixtureUS$ 300 - 350MOQ: 1 Unit
-
Fluke PM6666 Programmable Timer / CounterUS$ 995 - 1,035MOQ: 1 Unit
Brand Name
Keysight / Agilent
Model Number
N9912A
Specifications
NEW Agilent Keysight HP N9912A -104 FieldFox Handheld RF Combination Analyzer, 4 Ghz
Product Description
FieldFox RF analyzers are designed to withstand your toughest working conditions. To accelerate your work, each operating mode has a task-driven user interface that saves time in the field. Step up to FieldFox – and boost your readiness.
The N9912A’s base function is a cable and antenna analyzer and it can be configured to include a spectrum and transmission/reflection 1-port vector, 2-port scalar network analyzer. FieldFox can be ordered with additional capabilities: power meter, independent signal generator and interference analyzer.
The following accessories are included with every FieldFox: AC/DC adapter, battery, soft carrying case, LAN cable, Quick Reference Guide and User’s Guide. In addition, Keysight Technologies offers a standard 3-year warranty on all RF and microwave FieldFox analyzers. Please note that for a short time, online Quotes will reflect a charge for the 3-year warranty. This charge will be waived when an order is placed.
Applications
- Cell site management – cable and antenna test
- RF spectrum monitoring and interference analysis
- Active and passive device test
Accuracy
- Get precise measurements that agree with benchtop results
- QuickCal – Built-in calibration – no cal kit required
- CalReady – Immediate distance-to-fault measurements at the test port
Rugged
- Dust-free design with no fans, no vents extends instrument reliability in harsh environments
- Water-resistant; withstands salty, humid environments
- MIL-PRF-28800F Class 2 compliant
- GPS data with external USB GPS receiver
Specifications
Cable and antenna analyzer (CAT), vector network analyzer (VNA)
- 2 MHz to 4 GHz
- Directivity > 42 dB
- CAT: Distance-to-fault, return loss, cable loss
- VNA: S11 mag and phase, S21 mag, time doman with gating
Spectrum analyzer, interference analyzer
- 5 kHz to 4/6 GHz
- DANL: -148 dBm, +18 dBm TOI
- Spectrogram, waterfall display, record and playback
Independent source, vector voltmeter (VVM), power sensor and channel power measurements
- RF source: 2 MHz to 4/6 GHz, CW and tracking
- VVM: 2 MHz to 4/6 GHz, compare phase and electrical length
- Average and peak power measurements with USB sensor
- Channel power measurements: 100 kHz to 4 GHz, no sensor needed
FieldFox instrument attributes
- New: Remote control via iPad or iPhone
- Battery life: 4-hours; weight: 2.8 kg or 6.2 lbs
- Operating temperature: -10 to +55 °C (14 to 131 °F)
Options:
- 104 - 4 GHz cable and antenna analyzer
Accessories Included:
- 8121-1809 - Cable-Assembly Power-Cord
- N9912-90002 - Quick Reference Guide
- N9910-8001 - Soft carrying case with backpack and shoulder strap
- 0950-5014 - Power supply
- N9912-99001- User guide, printed
- 9320-6674 - CHina RoHS Addendum for Network Analyzer
- 5185-1605 - Envelope-Calibration Certificate
- 1420-0891 - Batter Li-Ion 10.8V
- 5190-1894 - Software/firmware addendum
