Rohde & Schwarz ZVL3 -K1 Vector Network Analyzer / Spectrum Analysis
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
United States
Brand Name:
Rohde & Schwarz
Model Number:
ZVL3-K1
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
United States
Brand Name
Rohde & Schwarz
Model Number
ZVL3-K1
Specifications
Rohde & Schwarz ZVL3-K1 Vector Network Analyzer / Spectrum Analysis.Network analyzer plus options for spectrum analysis and absolute power measurements in one extremely light, compact, instrument with a frequency range from 9 kHz to 3 GHz.
Specifications
- The price of a low cost instrument, the features and performance of a middle class instrument, the weight and form of portable instrument
- Adresses the entire market for design, production, service and installation
- Universal RF analysis. The most important instruments in one box:
- bidirectional 2-port vector network analyzer to characterize all 4 S-parameters
- optional spectrum analyzer
- optional power meter (with an R&S NRP power sensor)
- Measurement of S-parameters, impedance, admittance and stability
- Measurement output as Smith chart, inverted Smith chart, magnitude and phase, polar diagram, real / imaginary, group delay, VSWR
- Very high number of traces and channels, overlay display of traces and different channels in a single diagram
- Evaluation of traces within up to 10 ranges: max, min, rms, mean, std deviation, electrical length, phase delay
- Evaluation of band pass filters in terms of center frequency, bandwidth, quality factor, attenuation
- Intuitive user interface for hard and soft key or mouse control.. Dialogues and wizards for more complex tasks guide through the measurement. A context sensitive on-line help function explains the used functions in detail and provides the associated remote commands for easy programming. Undo and redo functions. Operation from remote locations via remote desktop function. Operating System Windows XP
- Easy export of the test setups, measurement results or screen shots to the internal flash disk or to an USB stick.Export or import of measurement data in ASCII or Touchstone format. Remote control via 100/10 base T-LAN interface or optional GPIB interface
- Fully portable; weighs less than 7 kg, optional battery power
Option:
K1 - Spectrum Analysis
Purchase Includes:
ZV-Z121 - N CalKit 50 OHM Female (like New)
