Hot Sale Rotary Dryer, Rotary Kiln Dryer, Rotary Dryer

FOB Price

USD $470,000 - $700,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Rotary Drying Equipment
Place of Origin	Henan, China	Brand Name	Zhongde
Model Number	3.6*28m	Voltage	380V
Certification	BV,CE,TUV	Warranty	1 year
After-sales Service Provided	Engineers available to service machinery overseas

Characteristics:

1.The cylinder protect itself, thermal efficiency can up to 95%.

2.The whole length of the dryer reduced to 50% approximately than mono-cylinder and reduced land investment to 50% approximately

3.Cylinder adopts heat-resistant and wear-resistant steel plate welding with long service life and easy maintenance.

4.High thermal efficiency , temperature of outer cylinder is 60or below(temperature of outer mono-cylinder is high to 150°C)

5.Low temperature of outlet, long-service of dust removal machine. It also can be directly connected to air box pulse bag filter.

6.Without gear and pinion drive, but wheel rotation applied, level operation of the complete machine makes system simple and reasonable.

7.Air heater could match boiling furnace, or oil furnace can also be applied, which can dry materials with size below 20mm.

8.Final moisture index can be adjusted according to requirements of customers.

Technical Parameter:

Specification(m)	Shell Cubage(m 3 )	Capacity(t/h)	Installation Obliquity(%)	Highest Inlet Air Temperature(°C)	Main Motor (KW)
Φ1.2×8.0	9	1.9~2.4	3~5	700~800	7.5
Φ1.2×10	11.3	2.4~3.0	3~5	700~800	7.5
Φ1.5×12	21.2	4.5~5.7	3~5	700~800	15
Φ1.5×14	24.7	5.3~6.6	3~5	700~800	15
Φ1.5×15	26.5	5.7~7.1	3~5	700~800	15
Φ1.8×12	30.5	6.5~8.1	3~5	700~800	18.5
Φ1.8×14	35.6	7.6~9.5	3~5	700~800	18.5
Φ2.2×12	45.6	9.7~12.2	3~5	700~800	22
Φ2.2×14	53.2	11.4~14.2	3~5	700~800	22
Φ2.2×16	60.8	13.0~16.2	3~5	700~800	22
Φ2.4×14	63.3	13.5~16.9	3~5	700~800	37
Φ2.4×18	81.4	17.4~21.7	3~5	700~800	37
Φ2.4×20	90.4	19.3~23.1	3~5	700~800	45
Φ2.4×22	99.5	21.2~26.5	3~5	700~800	45
Φ2.6×24	127.4	27.2~34.0	3~5	700~800	55
Φ3.0×20	141.3	30.1~37.7	3~5	700~800	75
Φ3.0×25	176.6	37.7~47.1	3~5	700~800	75
Φ3.2×25	201	42.9~53.6	3~5	700~800	90
Φ3.6×28	285	60.8~76.0	3~5	700~800	160

Pictures:

Production Process of Rotary Dryer:
