Specifications
1. Mounted on a trailer.2. Its max. depth is 200m.
3. It can drill various soft and hard rock.
4. BV & SGS certificate.
XY-200F geological prospecting drill rig--Max. 200m
Brief Introduce
XY-200F is widely used for Water well drilling, Geological Exploration and Prospecting, Geothermal wells, Blast-hole, Irrigation projects, etc.
Attracting features
1. It can move.
Slide base: It is to make machine move when you need to adjust drilling position.
2. It has different types.
Four-wheel, crawler.
3. Hydraulic control system
With integrative drilling tower, supported by two high strength oil cylinder, hydraulic controlling the rise and fall of the tower. Operation is extremely convenient, saving time and labor effort, creat max. benefit for the user.
4. Different bits
Three-wing Bit, Alloy Bit, Diamond Bit. According to your Geological conditions, I can help you choose suitable bit.
5. Spare parts
We provide factory cost accessory all year round.
6. Power
Diesel engine.
7. Easy to be disassembled, installed and operation, the heaviest part is less than 100kg, convenient for maintenance and transport.
Machine details
Specification
Drilling depth |
200m |
Maximum borehole caliber |
400mm |
Minimum borehole caliber |
75mm |
Diameter of Drill pipe |
42, 50, 60mm |
Drilling angle |
90°~75° |
Weight(Not include power) |
1700kg |
Unity machine dimension |
2750*950*1600mm |
Company Certificate
Defy tips:
How to choose a suitable machine?
1. What will you do using drilling rig?
---For water project, core sample, soil test, mineral prospect or others?
2. The depth you need?
---For water well, generally, 30-200m. For core sample, 30-600m, even more.
3. Any requirements to hole diameter?
---Within a certain range, the smaller diameter, the deeper depth. Mathematically, we call it inversely proportional.
4. Working land condition?
A. soil, sand, weathered land, etc. soft stratum.
B. soil, sand, soft and hard rock stratum, mixed one.
C. Mainly hard rock, like granite.
Based on the above information, experienced engineers will help you recommend suitable machine. If you have special demands, please tell us in advance.
