Specifications
XY-150 Trailer Blasthole Drilling Equipment1. diesel engine
2. Mobile trailer
3. Hydraulic system
4. SPT,CPT available
XY-150 Trailer Mounted Blasthole Drilling Equipment
1. wide application: geological prospecting, coring and sampling, water well drilling, ground hole drilling;
2. big capacity: Max depth 150m, caliber 400-75mm;
3. power supply: diesel engine as power. Convenient for place with sufficient electricity.
4. trailer mounted mobile base. Two or four wheels, can be dragged on tractor or cars;
5. hydraulic control system, more convenient and safe to operation with smooth working performance;
6. rotating speed is up to 1010 rpm, very high speed;
7. compact structure. Easy to dismantle and assemble. One person is able to carry it;
8. SPT, CPT are available.
Specifications:
1. Overall parameters | |
Drilling depth |
150m |
Maximum open hole caliber |
400mm |
End hole caliber |
75mm |
Diameter of drill rod |
50mm |
Drilling angle |
90~75 |
Weight(not include power) |
760kg |
Dimension |
2000mm*1000mm*1400mm |
2. Vertical shaft | |
Rotating speed |
140, 295, 470,790,1010 r/min |
Feeding stroke |
450mm |
3.Hoist | |
Max. single line hoisting capacity |
1600Kg |
Diameter of wire rope |
12mm |
Volume of winding drum |
35m |
Hug floodgate caliber |
245mm |
Hug floodgate belt width |
70mm |
4.Mud pump | |
Type |
Horizontal single urn twin-action |
Rate of flow |
95/77L/min |
MAX. pressure |
1.2MPa |
Working pressure |
0.7MPa |
Diameter of water inlet tube |
50mm |
Diameter of water outlet tube |
42mm |
5.Power | |
Diesel engine |
18HP, 2200r/min |
Electrical motor |
11KW, 1460r/min |
Spare parts
On-site working
Company Profile
Established in 1970s, Zhengzhou Defy has grown into one powerful drilling equipment manufacturer. With 7 professionals and dozens of technician for technical support, we always supply the most professional and practical solutions for our customers and users. Up to now, our drilling rigs have been exported to many countries arround the world, mainly Kenya, Chili, Mexico, France, Slovinia, Tanzania, etc with good feedbacks from our clients.
Quality Certificate
Remarks:
We will help customers create a complete set of drilling equipment, ensuring you can put it into direct drilling work immediately after you get the goods. Spare parts are also available here all year around. If you have interest in drilling rig, please kindly send us inquiries, or call us.
