DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts

DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts thumbnail-1
DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts thumbnail-2
DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts thumbnail-3
DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts thumbnail-4
DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts photo-1
DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts photo-2
DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts photo-3
DFHD-20 20ton Full Hydraulic Horizontal Directional Drilling Machine Self-propelled With Rubber Crawler Belts photo-4
US$ 35,000 - 55,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, horizontal directional drilling rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Zhengzhou Defy Mechanical & Electrical Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, horizontal directional drilling rig
Power Type Diesel
Place of Origin Henan, China
Brand Name DEFY
Model Number DFHD-20
Usage Other, construction pipe line laying project
Power(W) Cummins 110KW
Dimension(L*W*H) 5900*2100*2000 mm
Weight 6500 kg, 6500 kg
Certification SGS
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas



Product Description

 Product Application



   The DFHD-20 is a full hydraulic Horizontal Directional Drilling Rig self-propelled with rubber crawler belts, integrated with power station and main power. It is convenient for moving and powerful of flexibility.





DFHD-20 20ton full hydraulic Horizontal Directional Drilling Machine self-propelled with rubber crawler belts







Main Features



1.Equipped with Cummins diesel engine, the rig is powerful with stable property.
2.Adopting double-motor driven to the power head, the rotation will be steady with large torque. The power head equips with self-float shackle device to reduce the wearing of screw thread of the drilling rod, and then the operation will be easy and stable.
3.All hydraulic hoses are covered into the protecting jacket to increase the service life. Convenient angle-adjusting cylinder, flexible adjusting of incidence drilling angle, adopting motor-chain machanism to the feeding pull-back, the same thrust power and pulling capacity, effect the direction controlling at a long distance easily.
4.Double-holder makes the rod loading and unloading efficient.
5.The DFHD-20 rig is with the advantages of full hydraulic driven, centralization control, easy and nimble to operate.
Technical parameter



The Main Machine

Power of Engine

Cummins 110KW@2200rpm

No. of Engine Cylinder

6

Max. Push capacity

200KN

Max. Pull capacity

200KN

Rated Torque

6000 N·M

Hollow Spindle RPM

Lower   0-70r/min

High    0-140r/min

Feeding Stroke

3500 mm

Diameter of Guide Hole

dia 89 mm

Drilling Angle

8°—18°

Pressure of hydraulic system

20Mpa

Traveling speed

1.6 km/h

Structural Style

integrated with rubber crawler and mud pump

Dimension (L×W×H)

5900*2100*2000 mm

Weight

6500 kg



Our Services





Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

 DFHD-20 20ton full hydraulic Horizontal Directional Drilling Machine self-propelled with rubber crawler belts

Company Information

Established in 1970s, Zhengzhou Defy has growned into one leading drilling rig manufacturer in China, specilizing in drilling rig technology R&D, manufacturing, etc. We spark on conventional rotary drilling rig, new pneumatic drilling rig and are inventing another drilling rig with performance same as pneumatic one, but with much less investment for users.



Our drilling rigs are widely used for water well drilling, irrigation well drilling, geothermal hole drilling, mining blast hole drilling, construction pile work drilling, air-conditioner hole drilling, etc.



DEFY Brand drilling rigs have been widely exported to Chile, Russia, Australia, Malaysia, Kenya, Tansanzia, Zambia, South America, Peru, Zimbabwe, etc.



Every customer is very welcomed to our factory for visiting driling rig,  talking onsite and details. ^_^



DFHD-20 20ton full hydraulic Horizontal Directional Drilling Machine self-propelled with rubber crawler belts



FAQ

   How to choose a suitable drilling rig?

1. What will you do using drilling rig?
---For water project, core sample, soil test, mineral prospect or others?

2. The depth you need?
---For water well, generally, 30-200m. For core sample, 30-600m, even more.

3. Any requirements to hole diameter?
---Within a certain range, the smaller diameter, the deeper depth. Mathematically, we call it inversely proportional.

4. Working land condition?
A. soil, sand, weathered land, etc. soft stratum.
B. soil, sand, soft and hard rock stratum, mixed one.
C. Mainly hard rock, like granite.

Based on the above information, DEFY experienced engineers will help you recommend suitable machine and price. If you have special demands, please tell us ahead.
