373KW/466KVA 60HZ Diesel Generator

Generator set

Open type

Silent type

Model

FCG400E

FCG400ES

Engine model

QSX15-G8

Alternator brand

Engga,Stamford ,Marathon

Prime power    (kva/kw)

455kva/364kw

Standby power ( kva/kw)

400kva/500kw

Output voltage

415/240  or 400/230 or  380/220 v

Power factor

COSΦ=0.8(lagging)

Phase/wires

3 phase 4 wires

Fuel consumption

 @ 100%prime power

97.6 L/H @ 100% prime power

Rated speed (r/min.)

1800R.P.M ,60HZ

Dimension(L*W*H)

3300*1430*1950mm

Canopy:5000*1900*2250mm

Weigh (kgs)

 4430kgs

5435kgs

Noise level (at 7m)

98dba

80dba

Technical parameters of Engine:

 Engine model & Origial

Cummins USA QSX15-G8

Engine power prime

414kw

Cylinders

6L type,Four-stroke

Bore*stroke(mm)

137×169

Compression ratio

17.0:1

displacement

15L

Aspiration

Turbocharged and charge air cooled

 type of cooling

Close type cooling With fan & radiator

Type of Governor

Electronic speed control (EFI)

Filters system

Easy replacement type ,whole lubricating oil, Fuel filter and air filter, air filter for the paper core type.

Muffler and exhaust pipe

By using of industrial high performance muffler with flexible bellows flexible connected exhaust pipe , the generators can be reduced 15 ~ 20dBA Noise

Start type

24V DC start, start motor comes with built-in battery

Technical parameters of Engine:

Alternator Brand

Engga

Marathon

Stamford

Alternator Model

EG315M-320N

MP-320-4

HCI444FS

KW POWER

364 KW,60hz 1800 RPM

excited type

Brushless, self-excited(with auto voltage stability)

Grade for rotor, stator loop.

H GRADE

Protection Grade

IP21/IP22

Power quality

G3 Grade,GB/T2820

Rated Voltage

415/240  or 400/230 or  380/220 v

The Voltage Fluctuation

≤0.5%

Instantaneous Regulation of Voltage

+20%~-15%

Technical parameters of Control Panel: digital and AMF

Details

Brand: HK Harsen  Model: GU620A

Function:

·The controller has the following protection functions, such as

Emergency halting

Low accumulator alarming

Over speed protecting

Low oil voltage protecting

3 failure start alarming

Start motor take-off

Temperas halting protection
