Help Center14kw Yangdong Diesel Generator YND485D
Related Products
Specifications
Yangdong diesel generator1.Rated output:6.5-1200kw
2.open frame or silent canopy
3.high reliability
4.Low fuel consumpt
Yangdong Diesel generator(8KW-30KW)
1) Output range: 8kW - 30kW
2) Alternator: Xingnor,Qianghui,and so on
3) Water-cooled ,
4) 8hrs operation base tank ,
5) Key start / auto start ,
6) Sound-proof / weather-proof canopy is optional ,
7) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires alternating current output
8) Frequency: <3% ,
9) Frequency at stable state: <0.5%
10) Frequency deviation at instantaneous state: ≤+10%
11) Frequency return time: ≤3s
12) Voltage deviation at stable state: ≤+ -1%
13) Voltage deviation at instantaneous state: ≤+20%
14) Voltage return time: ≤4s
15) Voltage modulation: ≤0.3%
16) Standard configuration of gensets:
A) Engine: Perkins diesel engine
B) Engine type: Water-cooled, in line four-stoke, dry cylinder liner, direct injection
C) Alternator: Brushless and "H" class insulation
17) Control system:
A) Automatic alarm system: The unit has the acousto-optics alarm system and
Arrestor for any situation as the start defeat, the water is over temperature,
The oil pulls down, over speed, over load and over current
B) Operation display:
I) Unit voltage, tri-phase load current and frequency display
Ii) Water temperature, oil pressure display
Iii) Fuel level, fuel temperature display
Iv) Audible and visual alarm lamps and buzzers
18) Starting system: DC alternator is used to start engine
19) Short circuit protection: MCCB air switch
20) Cooling system: Combined cooling water tank fitted to meet the requirement of radiation at ambient temperature 40 degree ,0
21) Filter system: Oil, fuel and air filter
22) Accessories: Exhaust elbow, bellow, muffler
23) Supply standard collocation:
A) Diesel engine with all accessories, 3 filter, electric systems
B) Alternator
C) Steel structure
D) Fan and water tank cooling system
E) Flange connector
F) 12 / 24V starting motor and charge engine
G) Air cleaner, fuel cleaner, oil cleaner
H) On-board control panel
I) MCCB air conservation switch
J) 12 / 24V starting accumulator and battery line
K) Set shock absorber
L) High-efficient silencer
