30kw Yangdong Diesel Generator YSD490ZLD
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
FDK
Model Number:
FYG30
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
FDK
Model Number
FYG30
Output Type
AC Three Phase
Speed
1500RPM/1800RPM
Frequency
50HZ/60HZ
Rated Power
27KW
Rated Voltage
230/380v 240/415v
Specifications
yangdong diesel generatorEPA approved
Stamford Alternator
CE, ISO Approval
1year warranty,short delivery
yangdong diesel generator
Important Features:
Features and Benefits:
*The new and Improved, low speed, liquid-cooled diesel engine.
*Sound-Proof enclosure for a quieter operation.
*Fully automated starting system when used with ATS.
*Optional control panel to help monitor the generator.
*One year/1000 hours limited warranty(whichever is earlier).
*Wide array of system features that can be tailored to your specific application.
| Basic parameter | ||
| Type: | YangDong series | |
| Phase Number | Three Phase | |
| Model: | YSD490ZLD | |
| Rated Frequence(Hz) | 50 | 60 |
| Rated output power(kVA) | 38 | 34 |
| Rated rotation speed(rpm) | 1500 | 1800 |
| DC output | 12V | |
| Power factor cosØ | 0.8 | |
| Noise level(dBA(@)7m)(zero load~full load) | 70 | |
| Structure Type | Slient type | |
| Excitation | Self-excitation and constant voltage(AVR) | |
| Starter system | Electric | |
| Engine model | Y4100G | |
| Engine type | direct injection, water cooled, 4-stroke | |
| Displacement[L(cc)] | 3.298(3298) | |
| Alternator Type | YHG-20 | |
| Fuel tank capacity(L) | 75 | |
| Fuel consumption(g/kw.h) | ≤237 | |
| Continuous running time | 10H | |
| Bore×Stroke [mm(in)] | 100x105 | |
| Displacement[L(cc)] | 3.298 | |
| Shape parameter | ||
| Overall dimension[mm(inch)] | ( 1660 Χ 530 Χ 1100 ) | |
| Dry weight[kg(lbs)] | 850 ( ) | |
| Gross Weight(kg) | 920 | |
