1600kw MTU Diesel Generator 16V165TS3-3D

1600kw MTU Diesel Generator 16V165TS3-3D thumbnail-1
1600kw MTU Diesel Generator 16V165TS3-3D photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
FDK
Model Number:
FMG396-1760
Contact Supplier Request Quote Chat Now
Shenzhen Fudiankang Diesel Gensets Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name FDK
Model Number FMG396-1760
Output Type AC Three Phase
Speed 1500RPM/1800RPM
Frequency 50HZ/60HZ
Rated Power 1760KW
Rated Voltage 230/380V 240/415V

Specifications

generator
1.1600KW /2000KVA MTU generator
2.CE,ISO9001,CCC
3.low fuel consumption generator
4.1year warrranty,fast deliv

Specifications

generator
1.1600KW /2000KVA MTU generator
2.CE,ISO9001,CCC
3.low fuel consumption generator
4.1year warrranty,fast delivery

1600KW /2000KVA MTU diesel generator set

1.the specification of MTU genset:

Continuous Output 1600KW /2000KVA
Standby Output 1760KW /2200KVA
Rated Power Factor COSΦ=0.8(lagged)
Rated Output Voltage 400V/230V(400-10000v can be reached)
Rated Current(Continuous/Standby) 2880A/3168A
Rated Speed 1500rpm
Rated Frequency 50Hz
Starting Control Method: Auto Start/Handle Start
Dimension(mm) 6830x2840x2470
Genset Weight(KG) 13100kg
Steady State Voltage Adjustment(%) ≤ +/-1
Voltage Fluctuation(%) ≤ +/-0.5
Transient State Voltage Adjustment(%) +20~-15
Voltage Stable Time(s) ≤ 1
Steady State Frequency Adjustment(%) ≤ +/-1
Frequency Fluctuation(%) ≤ +/-0.5
Transient State Frequency Adjustment(%) +10~-7
Frequency Stable Time(s) ≤ 3
Fuel Consumption(100% Load)(g/kwh) 192g/kwh
Noise(LP7m) 96dB(A)

2.the specification of MTU engine:


Brand MTU
Model No. 16V4000G60
No. Of Cylinder 16
Bore*Stroke 165x190 mm
Starting Method 24V DC Voltage Bearing Starting Motor
Cooling Method Close Circuit Water Cooling
Oil-supply Method Electrical Injection
Speed-adjustment Method Electronic Governing
Aspiration Turbocharged Inter-cooled
Speed 1500rpm

3. the specification of alternator:


Brand Marathon
Model No. 744RSL4054
Rated Power/Capacity 1540KW / 1925KVA
Rated Voltage 400V/230V
Output Factor COSΦ=0.8(lagged)
Insulation Class H Class
Protection Class IP23
Wiring Methods 3 Phases and 4 Wires
Voltage Adjustment Methods DVR
Output Frequency 50Hz
