2000kw MTU Diesel Generator 16V165TS3D-3D

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

FDK

Model Number:

FMG396-2200

Shenzhen Fudiankang Diesel Gensets Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name FDK

Model Number FMG396-2200

Output Type AC Three Phase

Speed 1500RPM/1800RPM

Frequency 50HZ/60HZ

Rated Power 2200KW

Rated Voltage 230/380V 240/415V

Specifications

MTU diesel generator
1.Engine:MTU
2.Stamford/ENGGA alternator
3.Power : 2000kw
4.Water cooled

Specifications

2000KW Diesel Generator
1) Lower price than Cummins, MTU or Perkins, and reliable quality
2) Low fuel consumption

2000KW Diesel Generator

MODEL				FMG396-2200
Standby Power(50Hz)				2200 KW
Prime Power(50Hz)				2000 KW

ENGINE DATA
Manufacturer:				SHENZHEN FUDIANKANG(FDK) DIESEL GENSETS CO.,LTD.
Model:				H16V190ZL
Engine Max. Power:				2400KW
Displacement:				97.53L
Air Intake System:				Turbocharger
Governor:				Electrical
Cylinder No.:				16-cylinder in V
Bore and Stroke:				190×215(mm)
Compression Ratio:				14.5:1
Rated RPM:				1500rpm
Oil Consumption(g/kw.h):				1
Oil Capacity:				456 L
Water Capacity:				306 L
Max Back Pressure:				3 Kpa
Exhaust Temperature:				Below 600°C
Smoke:				552m3/min
Fuel Consumption at 100% Load :				200g/kw.h
Min Air Intake Area:				7.3M2
Min Air Exhuast Area:				5.8 M2
Start Method:				DC24V Start Motor
Overhaul Time:				More than 18000 Hour

ALTERNATOR DATA
Manufacturer:				Guangzhou Engga Generators Co.,Ltd.
Model:				EG500L-2000N
Rated Power:				2000KW
Connecting Type:				3 Phase and 4 Wires, “Y” type connecting
Power Factor:				0.8
Altitude:				Below 1000m
Exciter Type:				Brushless, self-exciting, with AVR
Insulation Class, Temperature Rise:				H/H

GENERATING SET DATA
Open Genset Size:				7000 19503000(mm)
Open Genset Weight:				16800 kg
