Low Carbon Steel Wire for Amouring Cable

Low Carbon Steel Wire for Amouring Cable photo-1
US$ 800 - 1,500 MOQ: 5 Metric Tons
Key Specifications
Get Latest Price
Steel Grade:
steel
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Wire Gauge:
1.24-5.50mm
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Steel Grade steel
Standard AISI, ASTM, BS, DIN, GB, JIS
Wire Gauge 1.24-5.50mm
Place of Origin Zhejiang, China
Type Galvanized
Application Manufacturing
Alloy Or Not Non-alloy
Special Use Cold Heading Steel
Model Number low carbon steel wire for armouring cable
Brand Name Wansheng





Low Carbon Steel Wire for Armouring Cable

1. Material: Q195,Q235,45#
2. Surface Coating: Galvanized

3. Characteristic: High tensile strength,small tolerance

                              Shiny surface, good corrosion prevention
4. Packing type:Spool or Coil

5. Application: Being used for armouring cable
6. Remarks during use and handling:

a. During transportation, handle softly and carefully, avoid bumping and damaging the steel wires. Moisture and rain prohibited. Steel wires must be stored in dry and well ventilated indoors
bPay attention to the direction of steel wires when paying-off. Be sure the spool or coil is rotationg freely as to achieve identical tension of all the steel wires

c.  In case of batch usage, the remaining should be repacked to avoid oxidizing of the surface



Technical parameters
Wire dia: 1.24-5.5mm; Tensile Strength:1290~1340Mpa

Nominal diameter (mm)

Tensile Strength

Stress at 1% Elongation

Twist

Elongation

Standard

mm

Mpa

Mpa

Times/360°

Lo=250mm



1.24~2.25

≥1340

≥1170

≥18

≥3.0%

As per GB,EN,IEC,JIS,ASTM standard, as well as customer's request

2.25~2.75

≥1310

≥1140

≥16

≥3.0%

2.75~3.00

≥1310

≥1140

≥16

≥3.5%

3.00~3.50

≥1290

≥1100

≥14

≥3.5%

3.50~4.25

≥1290

≥1100

≥12

≥4.0%

4.25~4.75

≥1290

≥1100

≥12

≥4.0%

4.75~5.50

≥1290

≥1100

≥12

≥4.0%



 NOTE:Providing engineer design as per cstomer's request.



Packing:

low carbon steel wire for amouring cable



Factory Picture:

low carbon steel wire for amouring cable
