UL3289 crosslinked copper green electrical wire
All our wires and cables are made of 99.99% pure oxygen free copper and high quality PVC which comply with the European Union RoHS environmental protection instruction.
SPECIFICATION: 6AWG
REFERENCE STANDARD: UL758,UL1581,CSA C22.2No.210.2
FLAME TEST: CSA FT2 flame test
RATED TEMPERATURE: 150 Deg Centigrade
RATED VOLTAGE: 600v
CONDUCTOR: 266/0.254 mm stranded tinned copper
INSULATION THICKNESS: 1.53mm
PE OUTER DIAMETER: 8.50mm
MAX. CONDUCTOR RESISTANCE: 1.403Ω/km
DIELECTRIC STRENGTH: 2000v
CONDUCTOR | INSULATION | MAX.COND. RESISTANCE (Ω/km,20°C,DC) | DIELECTRIC STRENGTH (VAC,1min) | |||
AWG | CONSTRUCTION (No./mm) | DIA. (mm) | THICKNESS (mm) | O.D. (mm) | ||
30 | 7/0.10 | 0.30 | 0.77 | 1.90 | 381 | 2,000 |
28 | 7/0.127 | 0.38 | 0.77 | 2.00 | 239 | 2,000 |
26 | 7/0.16 | 0.48 | 0.77 | 2.10 | 150 | 2,000 |
24 | 11/0.16 | 0.61 | 0.77 | 2.20 | 94.2 | 2,000 |
22 | 17/0.16 | 0.76 | 0.77 | 2.35 | 59.4 | 2,000 |
20 | 26/0.16 | 0.94 | 0.77 | 2.55 | 36.7 | 2,000 |
18 | 41/0.16 | 1.18 | 0.77 | 2.80 | 23.2 | 2,000 |
16 | 26/0.254 | 1.50 | 0.77 | 3.15 | 14.6 | 2,000 |
14 | 41/0.254 | 1.88 | 0.77 | 3.55 | 8.96 | 2,000 |
12 | 65/0.254 | 2.36 | 0.77 | 4.05 | 5.64 | 2,000 |
10 | 105/0.254 | 3.10 | 0.77 | 4.90 | 3.546 | 2,000 |
Packing: Coils: 305meters/coil or 610m/coil ,with PE film as outer package
Carton A:51cm*25cm*27cm Carton B: 33cm*33cm*33cm
Delivery: 3-15 days after receiving the down payment
Terms of payment : T/T (30% down payment and pay off after receiving the duplicate of B/L)
L/C at sight
1. Sample Available
2. OEM are offered
3. Buyers' label can be made
4. Fast delivery
5. Professional technology support
6. Convenient transportation path to DANYANG
1) Take flight to Shanghai,and aboard Harmony train from Shanghai Station to Danyang Staiion about one and half hour
2) Takeflight to Changzhou, and aboard Harmon train from Changzhou Station to Danyang Station about 20 minutes
