500W Waterbottle Lithium Battery for Electric Bike Kit

US$ 250 - 350 MOQ: 5 Sets

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

OEM

Model Number:

CR-500C

Hangzhou Top Mechanical And Electrical Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name OEM

Model Number CR-500C

500W Waterbottle lithium battery for electric bike kit

The advantage of this kits:

1, This kits can be installed on standard normal bike frame easily, no need to change the frame.

2, High starting torque, good performance on working and climbing.

3, Double brake levers with power off brake, more safety.

4, High efficiency, low consumption, long travel distance.

Kit model No.	CR-500C
Motor	500W (optional: 180-250W for EU, 250-350W for US, 200W for Ausralia&New Zealand)
Motor	front or rear, diameter 108mm for front and 135mm for rear, with sensor, disc brake option
Rim and spokes	Aluminum Alloy rim, 24"26"700C 28" with 36 spokes
Throttle	twist or thumb throttle with LCD display
Controller	48V hall sensor optional
Wheel	Hand-built motor wheel
PAS	8pcs strong magnets
Battery	48V 10Ah (optional others)
Brake levers	Aluminum alloy, in black color
Charger	110-240V, 2A
Max Speed	35-40KM
Max Load	100kg
N.W./G.W.	12kg/14kg

Our electric bike kit CR-500C including the below parts:

No.	Parts Name:	QTY:
1	Hand-built Motor wheel (spokes,rim, motor)	1 SET
2	Battery set	1 SET
3	Charger	1 PC
4	Controller	1 PC
5	Controller case/bag	1 PC
6	Display	1 SET
7	Brake Levers	1 PAIR
8	Throttle&grips	1 SET
9	PAS	1 SET
10	Manual,Zip ties,Screws,protection pipe	1 SET
