Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Winpower | Model Number: | UL2517 28AWG |
Type: | Insulated | Application: | Other, computer cable | Conductor Material: | Copper |
Conductor Type: | Stranded | Insulation Material: | PVC |
Product Description
UL2517 28 awg multi-core connecting able
All our wires and cables are made of 99.99% pure oxygen free copper and high quality PVC which comply with the European Union RoHS environmental protection instruction.
SPECIFICATION: UL2517 computer cable 28 AWG 7/0.127mm
RATED TEMPERATURE: 105 Degree Centigrade
RATED VOLTAGE: 300V
REFERENCE STANDARD: UL758,UL1581,CSA C22.2No.210.2
Pass FLAME TEST: UL VW-1, CSA FT1 flame test
Insulation material :PVC
Sheath Material :PVC
Braid material : tinned copper
CONDUCTOR: stranded tinned or bare copper
Conductor | Insulation | Max.COND. Resiatance (Ω/km,20°c ,DC) | |||
AWG | Construction (No./mm) | Core (No.) | Insulation thickness | O.D (mm) | |
30 | 7/0.10mm | 2-50 | 0.41 | 1.12 | 381 |
28 | 7/0.127mm | 2-50 | 0.41 | 1.2 | 239 |
26 | 7/0.16mm | 2-40 | 0.41 | 1.3 | 150 |
24 | 11/0.16mm | 2-30 | 0.41 | 1.43 | 94.2 |
22 | 17/0.16mm | 2-30 | 0.41 | 1.58 | 59.4 |
20 | 26/0.16mm | 2-30 | 0.41 | 1.76 | 36.7 |
18 | 41/0.16mm | 2-20 | 0.41 | 2 | 23.2 |
16 | 26/0.254mm | 2-16 | 0.41 | 2.32 | 14.6 |
14 | 41/0.254mm | 2-10 | 0.51 | 2.9 | 8.96 |
12 | 65/0.254mm | 2-7 | 0.79 | 3.94 | 5.64 |
10 | 66/0.32mm | 2-7 | 0.79 | 4.58 | 3.55 |
Packing: 1. 610m/coil ,with PE film as outer package .
2. 4 coils to be packed in one carton.
Delivery : 3-15 days after receiving the down payment
Terms of Payment: T/T (30 % down payment and pay off after receiving the duplicate of B/L)
L/C at sight
1. Sample Available
2. OEM are offered
3. Customer wire can be manufactured
4. Convenient transportation path to DANYANG
1) Take flight to Shanghai,and aboard Harmony train from Shanghai Station to Danyang Staiion about one hour
2) Take flight to Changzhou, and aboard Harmony train from Changzhou Station to Danyang station about 20 minutes.
